Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour -
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 2 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
SR Suntour XCE 28 Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano TY-300
Front Derailleur
Shimano M315 31.8mm
Shift Levers
Shimano SL-M315
Cassette
Shimano HG200 12-32t 7-Speed
Crank
Alloy forged 22x36t 7/8S
Chain
KMC Z7 GYBR
Pedals
VP-537 Black
Wheels
Rims
Mach1 ER20 19c
Tires
Kenda K1153 2.35" 22TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8 A:6º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS |
|---|---|
| Stack Reach Ratio | 1.63 mm |
| Bottom Bracket Height | 297 mm |
| Front Center | 615 mm |
| Rake | 42 mm |
| Trail | 95 mm |
| Stack | 576 mm |
| Reach | 354 mm |
| Top Tube Length | 515 mm |
| Seat Tube Angle | 74.5 ° |
| Seat Tube Length | 360 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 434 mm |
| Wheelbase | 1044 mm |
| Bottom Bracket Drop | 53 mm |
| Standover Height | 724 mm |
| Wheels | 27" |
| Rider Min Height | 145 cm |
| Rider Max Height | 160 cm |
Model Overview
MX 27 XS DIRT is part of the Orbea Mx model. Orbea launched 76 bikes of this model so far. You can easily view all of the Orbea Mx bikes models from 2020, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
MX 27 XS DIRT components
Fork
The MX 27 XS DIRT comes factory-installed with the SunTour fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on MX 27 XS DIRT are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The MX 27 XS DIRT has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
