Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour XCM -
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
SR Suntour XCM RL-Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano Deore M6000 GS Shadow Plus Direct Mount
Front Derailleur
Shimano Deore M6025 31.8mm
Shift Levers
Shimano Deore M6000
Cassette
Sun Race 11-42t 10-Speed
Crank
Alloy forged 26x36t 10S
Chain
KMC X10
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.5 mm |
| Bottom Bracket Height | 312.5 mm | 312.5 mm |
| Front Center | 623 mm | 639 mm |
| Rake | 42 mm | 42 mm |
| Trail | 91 mm | 86 mm |
| Stack | 588 mm | 598 mm |
| Reach | 375 mm | 399 mm |
| Top Tube Length | 542 mm | 569 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 388 mm | 430 mm |
| Head Tube Angle | 69 ° | 70 ° |
| Head Tube Length | 102 mm | 108 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1064 mm | 1080 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 795 mm | 820 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 155 cm | 164 cm |
| Rider Max Height | 166 cm | 180 cm |
Model Overview
MX 30 27.5 belongs to the Orbea Mx model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The SunTour XCM is included from the factory. It has a travel distance of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the MX 30 27.5 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea MX 30 27.5 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Orbea MX 30 27.5 bike has 2 sizes, in the range of 155 cm – 180 cm (5.09 ft – 5.91 ft). In short, you can easily find one that suits you.
