Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam AM 2018 Hydro Triple Butted 150mm travel 27.5 C-Boost 12x148 PF
Suspension Fork
Fox 34 Float Performance 150 3-Position QR15x110
Rear Shock
Fox Float DPS Performance 3-Position Evol custom tune 210x55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM GX XG-1275 Eagle 10-50t 12-Speed
Crank
SRAM Descendant CNC Eagle Dub Boost 32t
Chain
SRAM GX Eagle 12-Speed
Pedals
N/A
Wheels
Rims
DT M-1900 Spline 30c TLR 15/110mm CL
Tires
Maxxis Ardent 2.40" TLR 60 Tpi Exo Dual
Brakes
Brakes
Shimano MT501 BR500 Hydraulic Disc
Cockpit
Stem
Race Face Aeffect R 35mm interface
Handlebar
Race Face Aeffect 35 20mm Riser 760mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail
Seatpost
Race Face Aeffect Dropper 31.6x385/125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm | 1.31 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 696 mm | 724 mm | 748 mm | mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 114 mm | 113 mm | mm |
| Stack | 578 mm | 588 mm | 597 mm | 610 mm |
| Reach | 399 mm | 424 mm | 443 mm | 465 mm |
| Top Tube Length | 556 mm | 583 mm | 605 mm | 630 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1114 mm | 1142 mm | 1166 mm | mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm | 13 mm |
| Standover Height | 706 mm | 734 mm | 761 mm | 778 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
OCCAM AM H10 belongs to the Orbea Occam model. Orbea released 80 bikes variations of this model so far. Take a sneak peek at all Orbea Occam bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Orbea OCCAM TR H50 2019 has a starting price of 2499$. Orbea OCCAM TR M-LTD 2019 on the other hand is the most expensive at 7999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 3599$. In conclusion, this bike price is 0% more expensive than the price of the average Enduro bike.
OCCAM AM H10 components
Fork
Orbea OCCAM AM H10 2019 bike is equipped with the Fox Performance Float 34 fork, and has 150mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float DPS Performance 3-Position Evol custom tune 210x55mm, with a travel distance of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The OCCAM AM H10 2019 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea OCCAM AM H10 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Orbea OCCAM AM H10 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
