Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle, X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam AM OMR 150mm travel UFO 27.5 Boost 12x148 PF
Suspension Fork
Fox 34 Float Factory 150 FIT4 3-Pos-Adj QR15x110 Kashima
Rear Shock
Fox DPX2 Factory 3-Position Adjust Evol Kashima custom tune 210x55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle Gold
Shift Levers
SRAM X01 Eagle
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed
Crank
SRAM XX1 Eagle Dub Black Boost 32t
Chain
SRAM XX1 Eagle 12-Speed Gold
Chain Guide
OneUp Components ISCG05 Guide
Pedals
N/A
Wheels
Rims
DT Swiss XMC-1200 Spline 30c TLR 15/110mm IS (6-bolt)
Tires
Maxxis Ardent 2.40" 60 TPI Dual Exo TR
Brakes
Brakes
SRAM Guide RSC Hydraulic Disc
Cockpit
Stem
Race Face Turbine 35mm interface
Handlebar
Race Face Next R 35 20mm Rise 780mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail
Seatpost
Crank brothers Highline 31.6x425/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 696 mm | 724 mm | 748 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 114 mm | 113 mm |
| Stack | 578 mm | 588 mm | 597 mm |
| Reach | 399 mm | 424 mm | 443 mm |
| Top Tube Length | 556 mm | 583 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 432 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1114 mm | 1142 mm | 1166 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm |
| Standover Height | 706 mm | 734 mm | 761 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
OCCAM AM M-LTD is part of the Orbea Occam model. 80 bikes variations carry this model name so far. Take a sneak peek at all Orbea Occam bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Orbea OCCAM TR H50 2019 has a starting price of 2499$. Orbea OCCAM TR M-LTD 2019 on the other hand is the most expensive at 7999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 7999$. In conclusion, this bike price is 122.26% higher than the price of the average Enduro bike.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Fox DPX2 Factory 3-Position Adjust Evol model, with a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Orbea OCCAM AM M-LTD 2019, has a 27.5″ carbon model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea OCCAM AM M-LTD has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
OCCAM AM M-LTD comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Orbea model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
