Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 150mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 170cm
MD
160cm - 180cm
LG
170cm - 190cm
XL
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam OMR. Concentric Boost 12x148 rear axle. Pure Trail geometry. Internal cable routing. Asymmetric design. 29" wheels
Suspension Fork
Fox 34 Float Factory 140 FIT4 Remote-Adjust Push-lock 2-Position QR15x110 Kashima
Rear Shock
Fox Float Factory Remote Push-lock Evol Kashima custom tune 210x50mm
Drivetrain
Rear Derailleur
SRAM XX Eagle AXS
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM XX-1297 Eagle 10-52t 12-Speed
Crank
SRAM XX Eagle Dub Black 32t
Chain
SRAM XX Eagle 12-Speed
Wheels
Rims
Oquo Mountain Performance MP30LTD
Tires
Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Speed Grip, Addix, Brown
Brakes
Brakes
SRAM Level Ultimate 4 piston Stealth Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC10 Alu SL, 0º
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Grips
Ergon GXR
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Fizik Terra Ridon X1 145mm
Seatpost
Fox Transfer SL Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.389 mm | 1.323 mm | 1.273 mm | 1.229 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 753 mm | 780 mm | 807 mm | 838 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 119 mm | 121 mm | 120 mm |
| Stack | 611 mm | 615 mm | 624 mm | 633 mm |
| Reach | 440 mm | 465 mm | 490 mm | 515 mm |
| Top Tube Length | 570 mm | 596 mm | 622 mm | 649 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 405 mm | 415 mm | 430 mm | 460 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1191 mm | 1218 mm | 1245 mm | 1276 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
Model Overview
OCCAM SL M-LTD belongs to the Orbea Occam model. Orbea released 91 bikes variations of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Orbea OCCAM SL H30 2024 is the most affordable bike of this model and has a price of 2964$. On the other hand, Orbea OCCAM SL M-LTD 2024, is the most expensive and costs 10588$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2024 and its price was 10588$. If we compare this with the average Enduro bike cost we notice that the price is 194.19% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The OCCAM SL M-LTD comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The OCCAM SL M-LTD has a rear shock with a travel of 150mm. The model Fox Float Factory Remote Push-lock Evol is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on OCCAM SL M-LTD are the 29″ carbon type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea OCCAM SL M-LTD has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Orbea OCCAM SL M-LTD bike has 4 sizes, in the range of 150 cm – 200 cm (4.92 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Orbea model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
