Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam TR 2018 OMR 120mm travel UFO 29/27.5+ Boost 12x148 PF
Suspension Fork
Fox 34 Float Performance 130 3-Position QR15x110
Rear Shock
Fox Float DPS Performance 3-Position Evol custom tune 184x44mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX PG-1230 Eagle 11-50t 12-Speed
Crank
SRAM Descendant CNC Eagle Dub Boost 32t
Chain
SRAM NX Eagle 12-Speed
Pedals
N/A
Wheels
Rims
DT M-1900 Spline 25c TLR 15/110mm CL
Tires
Maxxis Forekaster 2.35" 120 TPI TLR Dual Exo
Brakes
Brakes
Shimano MT501 BR500 Hydraulic Disc
Cockpit
Stem
Race Face Ride
Handlebar
Orbea OC-II Flat 760mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail
Seatpost
Race Face Aeffect Dropper 31.6x385/125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.41 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 689 mm | 717 mm | 740 mm | 768 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 106 mm | 107 mm | 106 mm | 106 mm |
| Stack | 589 mm | 599 mm | 608 mm | 622 mm |
| Reach | 399 mm | 424 mm | 443 mm | 465 mm |
| Top Tube Length | 565 mm | 592 mm | 614 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1115 mm | 1143 mm | 1166 mm | 1194 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 718 mm | 736 mm | 762 mm | 775 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
OCCAM TR M30 belongs to the Orbea Occam model. There are 80 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Orbea OCCAM TR H50 2019 has a starting price of 2499$. Orbea OCCAM TR M-LTD 2019 on the other hand is the most expensive at 7999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea OCCAM TR M30 price was 3999$. Comparing the average cost of a Trail bike to this one, you will see that OCCAM TR M30 price is 44.79% higher.
Overview of components
Fork
The OCCAM TR M30 comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Orbea OCCAM TR M30 bike has the Fox Float DPS Performance 3-Position Evol custom tune 184x44mm model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The OCCAM TR M30 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The OCCAM TR M30 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
OCCAM TR M30 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orbea OCCAM TR M30 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
