Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
LG
178cm - 189cm
XL
186cm - 199cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Hydro High Polished 2020 Alloy link Boost PF Taper UFO2 I-Line
Suspension Fork
Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano SLX M7100
Cassette
Shimano SLX M7100 10-51t 12-Speed
Crank
Shimano XT M8100 32t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M7100
Pedals
N/A
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Maxxis Ardent 2.2" FB Dual Exo TR
Brakes
Brakes
Shimano MT501 BR500 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
OC1 Flat 31.8mm 740mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia SL X-Cross Flow
Seatpost
Race Face Ride 31.6x375mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.53 mm | 1.35 mm | 1.4 mm | 1.36 mm | 1.31 mm | 1.29 mm | 1.33 mm |
| Bottom Bracket Height | 327 mm | 334 mm | 327 mm | 334 mm | 334 mm | 327 mm | 327 mm | 334 mm |
| Front Center | 663 mm | 669 mm | 692 mm | 699 mm | 723 mm | 717 mm | 742 mm | 749 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 86 mm | 89 mm | 96 mm | 97 mm | 89 mm | 89 mm | 97 mm |
| Stack | 591 mm | 598 mm | 596 mm | 603 mm | 613 mm | 605 mm | 619 mm | 627 mm |
| Reach | 412 mm | 392 mm | 440 mm | 430 mm | 451 mm | 461 mm | 481 mm | 471 mm |
| Top Tube Length | 569 mm | 572 mm | 598 mm | 601 mm | 615 mm | 622 mm | 646 mm | 648 mm |
| Seat Tube Angle | 75 ° | 74 ° | 75 ° | 74 ° | 74 ° | 75 ° | 75 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 432 mm | 432 mm | 470 mm | 470 mm | 520 mm | 520 mm |
| Head Tube Angle | 69 ° | 68 ° | 69 ° | 68 ° | 68 ° | 69 ° | 69 ° | 68 ° |
| Head Tube Length | 90 mm | 90 mm | 95 mm | 95 mm | 105 mm | 105 mm | 120 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1099 mm | 1106 mm | 1128 mm | 1136 mm | 1160 mm | 1153 mm | 1178 mm | 1186 mm |
| Bottom Bracket Drop | 47 mm | 40 mm | 47 mm | 40 mm | 40 mm | 47 mm | 47 mm | 40 mm |
| Standover Height | 727 mm | 729 mm | 737 mm | 744 mm | 754 mm | 747 mm | 754 mm | 761 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 168 cm | 178 cm | 178 cm | 186 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 180 cm | 189 cm | 189 cm | 199 cm | 199 cm |
Model Overview
OIZ H20 is an Orbea Oiz model. Orbea launched 78 bikes of this model so far. Take a sneak peek at all Orbea Oiz bikes models from 2020, by clicking here.
Model range prices
Orbea OIZ H30 2020 is the most affordable bike of this model and has a price of 2599$. On the other hand, Orbea OIZ M-LTD 27.5 2020, is the most expensive and costs 8299$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2020 for 2999$. In conclusion, this bike price is 8.58% more expensive than the price of the average Trail bike.
OIZ H20 components
Fork
The OIZ H20 comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Fox i-line DPS Performance 120mm Remote model, with a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the OIZ H20 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The OIZ H20 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
