Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Factory Float 32
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMR 2019 Boost PF Taper UFO2 I-Line
Suspension Fork
Fox 32 Float SC Factory 100 FIT4 Remote-Adj Push-Unlock QR15x110 Kashima TR Suspension Pack 120mm Front/Rear
Rear Shock
Fox i-line DPS Factory Remote Push-Unlock Evol custom tune190x40mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle Gold
Shift Levers
SRAM XX1 Eagle Gold
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed
Crank
SRAM XX1 Eagle Dub Gold Boost 34t Rotor QX1 DM SRAM 32t Chainring (EXTRA) Rotor QX1 DM SRAM 34t Chainring (EXTRA)
Chain
SRAM XX1 Eagle 12-Speed Gold
Pedals
N/A
Wheels
Front Hub
Fox Kabolt Boost
Rear Hub
Fox Kabolt Boost
Rims
Mavic Crossmax Pro Carbon TL 6-Bolt
Tires
Maxxis Ikon 2.20" TLR 120 TPI 3C Exo Maxxis Forekaster 2.35" TLR (F) / Ardent Race 2.2" TLR (R)
Brakes
Brakes
SRAM Ultimate Carbon Gold Hydraulic Disc Shimano XTR M9100 Hydraulic Disc
Cockpit
Stem
FSA K-Force
Handlebar
FSA K-Force Flat 760mm Di2 compatible
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia X-LR Kit Carbonio S
Seatpost
FSA K-Force Light SB0 31.6x400mm Di2 compatible Race Face Aeffect Dropper 31.6x385/125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.43 mm | 1.35 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 328 mm | 327 mm | 327 mm | 327 mm | 327 mm |
| Front Center | 658 mm | 663 mm | 692 mm | 717 mm | 742 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 563 mm | 591 mm | 596 mm | 605 mm | 619 mm |
| Reach | 412 mm | 412 mm | 440 mm | 461 mm | 481 mm |
| Top Tube Length | 562 mm | 569 mm | 598 mm | 622 mm | 646 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 405 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 90 mm | 95 mm | 105 mm | 120 mm |
| Chainstay Length | 430 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1086 mm | 1099 mm | 1128 mm | 1153 mm | 1178 mm |
| Bottom Bracket Drop | 29 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 722 mm | 722 mm | 737 mm | 747 mm | 754 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
OIZ M-LTD belongs to the Orbea Oiz model. Orbea released 78 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea OIZ M50 2018 has a starting price of 3499$. Orbea OIZ M-LTD 2018 on the other hand is the most expensive at 8299$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2018, its price was 8299$. Comparing this to the average Trail bike price, we see that the price is 200.47% more expensive.
Overview of components
Fork
The OIZ M-LTD comes factory-installed with the Fox Factory Float 32 fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on OIZ M-LTD are the 27.5″ carbon type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
OIZ M-LTD comes in 5 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the OIZ M-LTD. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
