Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle AXS -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMX, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SC Factory 120 FIT4 Remote-Adj Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Factory 120mm Remote Push-Unlock Evol Kashima custom tune 190x45mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS
Shift Levers
SRAM XX1 Eagle AXS
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed Rainbow
Crank
SRAM XX1 Eagle Dub Grey Boost 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM XX1 Eagle 12-Speed rainbow
Wheels
Rims
OQUO Mountain Performance MP30LTD Carbon
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
SRAM Ultimate Carbon Black Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP10 Alu SL, -10º
Handlebar
OC MP10 Mountain Performance Carbon, Width 760, Sweep 9
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Selle Italia SLR Boost Fill Carbon Rail Ø7x9 mm
Seatpost
Fox Transfer SL Factory Kashima Dropper 31.6
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.32 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 601 mm | 601 mm | 611 mm | 624 mm |
| Reach | 430 mm | 455 mm | 477 mm | 501 mm |
| Top Tube Length | 580 mm | 603 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1143 mm | 1168 mm | 1194 mm | 1224 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 736 mm | 746 mm | 746 mm | 755 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
OIZ M LTD belongs to the Orbea Oiz model. Orbea released 78 bikes variations of this model so far. You can easily view all of the Orbea Oiz bikes models from 2023, here.
Model range prices
Orbea OIZ H30 2023 is the most affordable bike of this model and has a price of 3299$. On the other hand, Orbea OIZ M LTD 2023, is the most expensive and costs 10499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 10499$. Comparing the average cost of a Trail bike to this one, you will see that OIZ M LTD price is 280.12% higher.
Overview of components
Fork
The OIZ M LTD comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox i-line DPS Factory 120mm Remote, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on OIZ M LTD are the 29″ carbon type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea OIZ M LTD is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Orbea OIZ M LTD bike has 4 sizes, in the range of 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
