Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMX, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SC Factory 120 FIT4 Remote-Adj Push to Lock QR15x110 Kashima
Rear Shock
Fox Float SL Factory 120mm Remote Push-lock Evol Kashima custom tune 190x45mm
Drivetrain
Rear Derailleur
SRAM XX Eagle SL AXS
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM XX-1299 Eagle SL 10-52t 12-Speed
Crank
SRAM XX SL Eagle Dub Black 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM XX-SL Eagle 12-Speed
Wheels
Rims
Oquo Mountain Performance MP30LTD, carbon hookless rim, DT240 S CL hub, 30mm internal width, Sapim CX-Ray TCS spokes, 29"
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
SRAM Level Ultimate Carbon 2 piston Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP10 Alu SL, -10º
Handlebar
OC MP10 Mountain Performance Carbon, Width 760, Sweep 9
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Selle Italia SLR Boost Fill Carbon Rail Ø7x9 mm
Seatpost
Fox Transfer SL Factory Kashima Dropper 31.6
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.32 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 601 mm | 601 mm | 611 mm | 624 mm |
| Reach | 430 mm | 455 mm | 477 mm | 501 mm |
| Top Tube Length | 580 mm | 603 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1143 mm | 1168 mm | 1194 mm | 1224 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 736 mm | 746 mm | 746 mm | 755 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
OIZ M LTD completes the Orbea Oiz model. 78 bikes variations carry this model name so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Orbea OIZ M-PRO 2024 is the most affordable bike of this model and has a price of 6599$. On the other hand, Orbea OIZ M LTD 2024, is the most expensive and costs 10999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2024 for 10999$. In conclusion, this bike price is 298.23% higher than the price of the average Trail bike.
Overview of components
Fork
The OIZ M LTD comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Fox Float SL Factory 120mm Remote, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The OIZ M LTD 2024 bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
OIZ M LTD comes in 4 sizes, that range from 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
