Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.
Suspension Fork
Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.
Drivetrain
Rear Derailleur
Shimano Ultegra R8000 SS
Front Derailleur
Shimano Ultegra R8000
Shift Levers
Shimano ST-8020
Cassette
Shimano Ultegra R8000 11-30t 11-Speed
Crank
Shimano Ultegra R8000 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
KMC X11-EL
Wheels
Rims
FULCRUM Racing 400 DB
Tires
Vittoria Rubino IV G2.0 TLR 700x25c
Brakes
Brakes
Shimano R8070 Hydraulic Disc
Cockpit
Stem
OC RP10 Road Performance ICR, -8º, IFC02 Computer mount interface
Handlebar
OC RA10 Road Aero Carbon, Reach 80, Drop 125, Flare 5, w/Di2 hole
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Dimension T4.0 size143 mm
Seatpost
Orbea Orca Aero OMX, SB0/25, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.51 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 260 mm | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 570 mm | 575 mm | 579 mm | 580 mm | 590 mm | 600 mm | 614 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64.9 mm | 61.8 mm | 57.5 mm | 59 mm | 57.8 mm | 56.5 mm | 56.5 mm |
| Stack | 487 mm | 496 mm | 514 mm | 533 mm | 553 mm | 571 mm | 597 mm |
| Reach | 361 mm | 367 mm | 371 mm | 376 mm | 382 mm | 389 mm | 395 mm |
| Top Tube Length | 498.6 mm | 511.8 mm | 523.9 mm | 536.5 mm | 548.5 mm | 564.1 mm | 578 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 459 mm | 474 mm | 499 mm | 524 mm | 544 mm | 564 mm | 589 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 93.1 mm | 100.8 mm | 117.2 mm | 134.9 mm | 155.2 mm | 173.2 mm | 200.4 mm |
| Chainstay Length | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm |
| Wheelbase | 957 mm | 962 mm | 965 mm | 967 mm | 977 mm | 987 mm | 1001 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 708 mm | 719 mm | 741 mm | 766 mm | 785 mm | 802 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
ORCA AERO M20LTD belongs to the Orbea Orca model. Orbea released 214 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Orbea ORCA M40 2023 is the most economical model, with a starting price of 2799$. Orbea ORCA AERO M10iLTD 2023 on the other hand costs 10899$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Aero bikes average price
If you want an acceptable Aero bike you should know that the average price is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4999$. Doing a quick comparison, we notice that ORCA AERO M20LTD price is 18.71% higher than the average cost of an Aero bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ORCA AERO M20LTD components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Orbea ORCA AERO M20LTD 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ORCA AERO M20LTD has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, finding one for you shouldn’t be a problem.
