Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.
Suspension Fork
Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.
Drivetrain
Rear Derailleur
Shimano 105 Di2 R7150
Front Derailleur
Shimano 105 Di2 R7150
Shift Levers
Shimano Di2 R7170
Cassette
Shimano 105 R7100 11-34t 12-Speed
Crank
Shimano 105 R7100 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano M7100
Wheels
Rims
Oquo Road Performance RP35PRO, alloy rim, 35mm profile, Zipp ZR1 hub, 19mm internal width, Sapim CX-Sprint spokes, 700C
Tires
Vittoria Corsa N.Ext G2.0 Foldable 700x28c
Brakes
Brakes
Shimano R7170 Hydraulic Disc
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Road Aero RA11 Carbon, Reach 80, Drop 125
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Scratch-M5 Pas T2.0 size 140mm
Seatpost
OC Road Aero RA10 Carbon, SB0/25, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.51 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 260 mm | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 570 mm | 575 mm | 579 mm | 580 mm | 590 mm | 600 mm | 614 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64.9 mm | 61.8 mm | 57.5 mm | 59 mm | 57.8 mm | 56.5 mm | 56.5 mm |
| Stack | 487 mm | 496 mm | 514 mm | 533 mm | 553 mm | 571 mm | 597 mm |
| Reach | 361 mm | 367 mm | 371 mm | 376 mm | 382 mm | 389 mm | 395 mm |
| Top Tube Length | 498.6 mm | 511.8 mm | 523.9 mm | 536.5 mm | 548.5 mm | 564.1 mm | 578 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 459 mm | 474 mm | 499 mm | 524 mm | 544 mm | 564 mm | 589 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 93.1 mm | 100.8 mm | 117.2 mm | 134.9 mm | 155.2 mm | 173.2 mm | 200.4 mm |
| Chainstay Length | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm |
| Wheelbase | 957 mm | 962 mm | 965 mm | 967 mm | 977 mm | 987 mm | 1001 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 708 mm | 719 mm | 741 mm | 766 mm | 785 mm | 802 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA AERO M30iLTD belongs to the Orbea Orca model. Orbea launched 214 bikes of this model so far. You can easily view all of the Orbea Orca bikes models from 2024, here.
Model range prices
The most economical model, the Orbea ORCA M30 2024 has a starting price of 2999$. Orbea ORCA M10iLTD PWR 2024 on the other hand is the most expensive at 11599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea ORCA AERO M30iLTD price was 4899$. If we compare this with the average Aero bike cost we notice that the price is 16.34% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
ORCA AERO M30iLTD has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the ORCA AERO M30iLTD bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The ORCA AERO M30iLTD has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 7 sizes. They vary from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, finding one for you shouldn’t be a problem.
