Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.
Suspension Fork
Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.
Drivetrain
Rear Derailleur
SRAM Rival eTAP AXS
Front Derailleur
SRAM Rival eTAP AXS
Shift Levers
SRAM Rival eTap AXS
Cassette
SRAM XG-1250 10-30t 12-Speed
Crank
SRAM Rival AXS Powermeter Dub 35x48t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
SRAM Rival 12-Speed
Wheels
Rims
Alloy 35, Tubeless, 700c, 19c, 24H
Tires
Vittoria Rubino G2.0 Foldable 700x25c
Brakes
Brakes
SRAM Rival eTap AXS
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Road Aero RA11 Carbon, Reach 80, Drop 125
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Dimension T4.0 size143 mm
Seatpost
OC Road Aero RA10 Carbon, SB0/25, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.51 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 260 mm | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 570 mm | 575 mm | 579 mm | 580 mm | 590 mm | 600 mm | 614 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64.9 mm | 61.8 mm | 57.5 mm | 59 mm | 57.8 mm | 56.5 mm | 56.5 mm |
| Stack | 487 mm | 496 mm | 514 mm | 533 mm | 553 mm | 571 mm | 597 mm |
| Reach | 361 mm | 367 mm | 371 mm | 376 mm | 382 mm | 389 mm | 395 mm |
| Top Tube Length | 498.6 mm | 511.8 mm | 523.9 mm | 536.5 mm | 548.5 mm | 564.1 mm | 578 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 459 mm | 474 mm | 499 mm | 524 mm | 544 mm | 564 mm | 589 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 93.1 mm | 100.8 mm | 117.2 mm | 134.9 mm | 155.2 mm | 173.2 mm | 200.4 mm |
| Chainstay Length | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm | 399 mm |
| Wheelbase | 957 mm | 962 mm | 965 mm | 967 mm | 977 mm | 987 mm | 1001 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 708 mm | 719 mm | 741 mm | 766 mm | 785 mm | 802 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA AERO M31eLTD PWR completes the Orbea Orca model. Orbea launched 214 bikes of this model so far. Take a sneak peek at all Orbea Orca bikes models from 2023, by clicking here.
Model range prices
Orbea ORCA M40 2023 is the most affordable bike of this model and has a price of 2799$. On the other hand, Orbea ORCA AERO M10iLTD 2023, is the most expensive and costs 10899$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2023, its price was 5699$. Doing a quick comparison, we notice that ORCA AERO M31eLTD PWR price is 35.34% more expensive than the average cost of an Aero bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ORCA AERO M31eLTD PWR components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the ORCA AERO M31eLTD PWR model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ORCA AERO M31eLTD PWR has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Orbea ORCA AERO M31eLTD PWR bike has 7 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, finding one for you shouldn’t be a problem.
