Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca carbon OMP, monocoque, tapered 1-1/8" - 1,5", PF 86mm, powermeter compatible, internal cable routing, EC/DC compatible, 130mm rear spacing, 27,2mm seat tube.
Suspension Fork
Orca OMP carbon fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts.
Drivetrain
Rear Derailleur
Shimano Dura-Ace 9100
Front Derailleur
Shimano Dura-Ace 9100
Shift Levers
Shimano Dura-Ace 9100
Cassette
Shimano Dura-Ace 9100 11-28t 11-Speed Shimano Dura-Ace R9100 11-25t 11-Speed Shimano Dura-Ace R9100 11-30t 11-Speed
Crank
Shimano Dura-Ace 9100 34x50t Shimano Dura-Ace R9100 39x53t Rotor Aldhu 36x52t Rotor 2INpower DM 34x50t Rotor 2INpower DM 36x52t
Bottom Bracket
BB86/BB92, press-fit
Chain
Shimano HG 901
Pedals
N/A
Wheels
Rims
Mavic Ksyrium UST Mavic Ksyrium Elite Black UST + Tires Fulcrum Racing Quattro Carbon Vittoria Elusion Carbon 30
Tires
Vittoria Rubino Pro 700x25 120TPI G+
Brakes
Brakes
Shimano Dura-Ace 9100
Cockpit
Stem
FSA Energy FSA OS-99 CSI
Handlebar
FSA Energy Compact FSA K-Force Compact Vision Metron 4D Compact
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Hard Black Scratch-2 Tirox size 143 mm Prologo Dimension T4,0 Black Selle Italia SLR Kit Carbonio Black
Seatpost
FSA SL-K SB20 27.2x350mm Di2 compatible FSA S-LK Offset SB0 27,2x350/400mm FSA K-Force Offset SB0 27,2x350/400mm FSA K-Force Offset SB25 27,2x350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.39 mm | 1.41 mm | 1.44 mm | 1.47 mm | 1.49 mm | 1.53 mm |
| Bottom Bracket Height | 271.5 mm | 271.5 mm | 271.5 mm | 271.5 mm | 271.5 mm | 271.5 mm | 271.5 mm |
| Front Center | 575 mm | 573 mm | 592 mm | 590 mm | 598 mm | 606 mm | 615 mm |
| Rake | 53 mm | 53 mm | 53 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 60 mm | 67 mm | 55 mm | 63 mm | 61 mm | 58 mm | 55 mm |
| Stack | 499 mm | 508 mm | 526 mm | 545 mm | 565 mm | 583 mm | 609 mm |
| Reach | 358 mm | 365 mm | 373 mm | 378 mm | 384 mm | 391 mm | 397 mm |
| Top Tube Length | 507.8 mm | 513.55 mm | 530.9 mm | 541.5 mm | 556.7 mm | 569 mm | 583 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.4 ° | 71.8 ° | 72.1 ° | 72.5 ° | 73 ° | 73.5 ° |
| Head Tube Length | 104 mm | 112 mm | 130 mm | 145 mm | 165 mm | 182 mm | 207.1 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm | 401 mm | 401 mm | 401 mm |
| Wheelbase | 962 mm | 960 mm | 979 mm | 977 mm | 989 mm | 996 mm | 1005 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 701 mm | 719 mm | 744 mm | 764 mm | 784 mm | 800 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
ORCA M10-PRO completes the Orbea Orca model. There are 214 bikes that carry this model name. Take a sneak peek at all Orbea Orca bikes models from 2018, by clicking here.
Model range prices
Orbea ORCA M40 2018 is the most economical model, with a starting price of 1899$. Orbea ORCA M10iLTD-D 2018 on the other hand costs 9399$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2018 and its price was 4999$. Comparing the average cost of a Race bike to this one, you will see that ORCA M10-PRO price is 49.22% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the ORCA M10-PRO bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea ORCA M10-PRO is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, you can easily find one that suits you.
