Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing, EC/DC compatible
Suspension Fork
Orbea Orca OMR ICR fork 2021, full carbon, 1-1/8" - 1.5" tappered head tube compatible, Thru axle 12x100m, thread M12x2P1, Speed release compatible droput.
Drivetrain
Rear Derailleur
SRAM Force eTAP AXS
Front Derailleur
SRAM Force eTAP AXS
Shift Levers
SRAM Force eTap AXS
Cassette
SRAM XG-1270 10-28t 12-Speed
Crank
SRAM Force Dub 33x46t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
SRAM Force 12-Speed
Wheels
Rims
FULCRUM Racing 700 DB
Tires
Vittoria Rubino IV G2.0 TLR 700x28c
Brakes
Brakes
SRAM Force eTap AXS
Cockpit
Stem
Orbea ICR -8º
Handlebar
OC2 Road Carbon, reach 80mm, drop 125mm
Headset
Acros Alloy 1-1/2" Internal Cable Routing
Seat
Saddle
Prologo Scratch-M5 Pas T2.0 size 140mm
Seatpost
OC2 Carbon 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.48 mm | 1.5 mm | 1.55 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 575 mm | 579 mm | 583 mm | 583 mm | 593 mm | 604 mm | 618 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64 mm | 61 mm | 56 mm | 58 mm | 58 mm | 55 mm | 55 mm |
| Stack | 519 mm | 528 mm | 546 mm | 565 mm | 585 mm | 603 mm | 629 mm |
| Reach | 373 mm | 378 mm | 383 mm | 388 mm | 394 mm | 401 mm | 407 mm |
| Top Tube Length | 516 mm | 529 mm | 541 mm | 554 mm | 566 mm | 582 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 105 mm | 113 mm | 130 mm | 148 mm | 168 mm | 186 mm | 213 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 978 mm | 982 mm | 986 mm | 987 mm | 997 mm | 1008 mm | 1022 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 741 mm | 753 mm | 772 mm | 793 mm | 813 mm | 831 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA M21eTEAM completes the Orbea Orca model. There are 214 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea ORCA M40 2022 is the most economical model, with a starting price of 2441$. Orbea ORCA M10iLTD PWR 2022 on the other hand costs 11148$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Orbea released this model in 2022, its price was 4999$. If we compare this with the average Race bike cost we notice that the price is 49.22% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ORCA M21eTEAM components
Fork material
ORCA M21eTEAM has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the ORCA M21eTEAM bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
ORCA M21eTEAM comes in 7 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, it won’t be difficult to find the right one for you.
