Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca carbon OMR 2024, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.
Suspension Fork
Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.
Drivetrain
Rear Derailleur
SRAM Force AXS 12s
Front Derailleur
SRAM Force eTAP AXS
Shift Levers
SRAM Force AXS
Cassette
SRAM XG-1270 10-33t 12-Speed
Crank
SRAM Force AXS Power Meter Dub 35x48t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
SRAM Force 12-Speed
Wheels
Rims
Oquo Road Performance RP35TEAM, carbon Mini Hook rim, 35mm profile, Zipp ZR1 hub, 21mm internal width, Sapim Sprint Oxi spokes, 700C
Tires
Vittoria Corsa N.Ext G2.0 Foldable 700x28c
Brakes
Brakes
SRAM Force AXS
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Road Performance RP21 Alu SL, Reach 80, Drop 125
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Fizik Vento Antares R7 Alloy Rail 140mm
Seatpost
OC Performance XP10-S Carbon, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.48 mm | 1.52 mm |
| Bottom Bracket Height | 268.5 mm | 268.5 mm | 268.5 mm | 270.5 mm | 270.5 mm | 270.5 mm | 270.5 mm |
| Front Center | 575 mm | 578 mm | 583 mm | 583 mm | 594 mm | 604 mm | 618 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 66 mm | 62.8 mm | 58.4 mm | 59.9 mm | 58.7 mm | 57.4 mm | 57.4 mm |
| Stack | 512 mm | 521 mm | 539 mm | 558 mm | 578 mm | 596 mm | 622 mm |
| Reach | 376 mm | 381 mm | 386 mm | 391 mm | 397 mm | 404 mm | 410 mm |
| Top Tube Length | 516.3 mm | 528.7 mm | 541.9 mm | 554.5 mm | 566.4 mm | 582.1 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 110.5 mm | 118.2 mm | 134.6 mm | 152.9 mm | 173.1 mm | 191.2 mm | 218.3 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 977 mm | 981 mm | 986 mm | 987 mm | 997 mm | 1007 mm | 1021 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 742 mm | 754 mm | 773 mm | 794 mm | 814 mm | 832 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
ORCA M21eTEAM PWR is an Orbea Orca model. There are 214 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Orbea ORCA M30 2024 is the most economical model, with a starting price of 2999$. Orbea ORCA M10iLTD PWR 2024 on the other hand costs 11599$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orbea released this model in 2024, its price was 6899$. Doing a quick comparison, we notice that ORCA M21eTEAM PWR price is 105.94% more expensive than the average cost of a Race bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ORCA M21eTEAM PWR components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the ORCA M21eTEAM PWR bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ORCA M21eTEAM PWR comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
ORCA M21eTEAM PWR comes in 7 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, you won’t have a problem finding one that suits you.
