Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing, EC/DC compatible
Suspension Fork
Orbea Orca OMR ICR fork 2021, full carbon, 1-1/8" - 1.5" tappered head tube compatible, Thru axle 12x100m, thread M12x2P1, Speed release compatible droput.
Drivetrain
Rear Derailleur
Shimano 105 Di2 R7150
Front Derailleur
Shimano 105 Di2 R7150
Shift Levers
Shimano Di2 R7170
Cassette
Shimano 105 R7100 11-34t 12-Speed
Crank
Shimano 105 R7100 34x50T with left side 4iiii Powermeter
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano M7100
Wheels
Rims
FULCRUM Racing 600 DB
Tires
Vittoria Rubino IV G2.0 Foldable 700x28c
Brakes
Brakes
Shimano R7170 Hydraulic Disc
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Road Performance RP30, Reach 80, Drop 125
Headset
Acros Alloy 1-1/2" Internal Cable Routing
Seat
Saddle
Prologo Scratch-M5 Pas T2.0 size 140mm
Seatpost
Carbon, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.48 mm | 1.5 mm | 1.55 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 575 mm | 579 mm | 583 mm | 583 mm | 593 mm | 604 mm | 618 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64 mm | 61 mm | 56 mm | 58 mm | 58 mm | 55 mm | 55 mm |
| Stack | 519 mm | 528 mm | 546 mm | 565 mm | 585 mm | 603 mm | 629 mm |
| Reach | 373 mm | 378 mm | 383 mm | 388 mm | 394 mm | 401 mm | 407 mm |
| Top Tube Length | 516 mm | 529 mm | 541 mm | 554 mm | 566 mm | 582 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 105 mm | 113 mm | 130 mm | 148 mm | 168 mm | 186 mm | 213 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 978 mm | 982 mm | 986 mm | 987 mm | 997 mm | 1008 mm | 1022 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 741 mm | 753 mm | 772 mm | 793 mm | 813 mm | 831 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA M30iTEAM PWR belongs to the Orbea Orca model. 214 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea ORCA M40 2022 is the most affordable bike of this model and has a price of 2441$. On the other hand, Orbea ORCA M10iLTD PWR 2022, is the most expensive and costs 11148$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 4499$. In conclusion, this bike price is 34.3% higher than the price of the average Race bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
ORCA M30iTEAM PWR has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The ORCA M30iTEAM PWR 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea ORCA M30iTEAM PWR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
ORCA M30iTEAM PWR comes in 7 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, you won’t have a problem finding one that suits you.
