Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM/MD
170cm - 180cm
MD/LG
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
Suspension Fork
Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 R9250
Front Derailleur
Shimano Dura-Ace Di2 R9250
Shift Levers
Shimano R9180
Cassette
Shimano Dura-Ace R9200 11-30t 12-Speed
Crank
Shimano Dura-Ace R9200 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano CN-9100
Wheels
Rims
Oquo Road Performance RP57LTD, carbon Mini Hook rim, 57mm profile, Zipp Cognition VS2 hub, 21mm internal width, Sapim CX-Ray spokes, 700C
Tires
Vittoria Corsa Pro G2.0 TLR 700x28c
Brakes
Brakes
Shimano R9270 Hydraulic Disc
Cockpit
Handlebar
Orbea Ordu OMX
Headset
FSA 1-1/8"-1" Integrated Aluminium Cup
Seat
Saddle
Fizik Argo Vento R5 size 140mm
Seatpost
Orbea Ordu OMX, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.75 mm | 0.776 mm | 0.776 mm | 0.821 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 578 mm | 614 mm | 614 mm | 654 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 481 mm | 516 mm | 516 mm | 566 mm |
| Reach | 641 mm | 665 mm | 665 mm | 689 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 59 mm | 96 mm | 96 mm | 149 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 971 mm | 1007 mm | 1007 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 781 mm | 781 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
ORDU M10iLTD is part of the Orbea Ordu model. Orbea released 35 bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Orbea ORDU M30iLTD 2024 is the most economical model, with a starting price of 7299$. Orbea ORDU M10iLTD 2024 on the other hand costs 10999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Triathlon bikes average price
If you want an acceptable Triathlon bike you should know that the average price is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Orbea ORDU M10iLTD price was 10999$. Comparing this to the average Triathlon bike price, we see that the price is 163.32% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the ORDU M10iLTD bike is equipped with the 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea ORDU M10iLTD is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
