Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM/MD
170cm - 180cm
MD/LG
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
Suspension Fork
Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 R8050 SS
Front Derailleur
Shimano Ultegra Di2 R8050
Shift Levers
Shimano R9180
Cassette
Shimano Ultegra R8000 11-28t 11-Speed
Crank
Rotor ALDHU Round 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano HG 701
Wheels
Rims
Vision 55 SC Disc Carbon TLR CL
Tires
Vittoria Rubino Pro IV G2.0 TLR 700x25c
Brakes
Brakes
Shimano R9170 Hydraulic Disc
Cockpit
Handlebar
Orbea Ordu OMX
Headset
FSA 1-1/8"-1" Integrated Aluminium Cup
Seat
Saddle
Fizik Argo Vento R5 size 140mm
Seatpost
Orbea Ordu OMX
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.75 mm | 0.776 mm | 0.776 mm | 0.821 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 578 mm | 614 mm | 614 mm | 654 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 481 mm | 516 mm | 516 mm | 566 mm |
| Reach | 641 mm | 665 mm | 665 mm | 689 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 59 mm | 96 mm | 96 mm | 149 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 971 mm | 1007 mm | 1007 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 781 mm | 781 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
ORDU M20iLTD is an Orbea Ordu model. 35 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Orbea ORDU M20LTD 2021 is the most affordable bike of this model and has a price of 5599$. On the other hand, Orbea ORDU M10iLTD 2021, is the most expensive and costs 9899$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Triathlon bikes
If you want an acceptable Triathlon bike you should know that the average price is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 7699$. If we compare this with the average Triathlon bike cost we notice that the price is 84.32% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
ORDU M20iLTD has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on ORDU M20iLTD are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ORDU M20iLTD comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
