Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XTR, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 171cm
SM
150cm - 171cm
LG
169cm - 190cm
MD
160cm - 181cm
LG
169cm - 190cm
LG
169cm - 190cm
XL
179cm - 200cm
XL
179cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 160mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 38 Float Factory 170 Grip2 QR15x110 Kashima
Rear Shock
Fox DHX2 Factory 2-Position Adjust SLS Spring Cr 230x60mm
Drivetrain
Rear Derailleur
Shimano XTR M9100 SGS Shadow Plus
Shift Levers
Shimano XTR M9100
Cassette
Shimano XTR M9100 10-51t 12-Speed
Crank
Race Face Era 32t
Chain
Shimano CN-9100
Chain Guide
e*thirteen CL52 30-36t black
Wheels
Rims
OQUO Mountain Control MC32LTD Carbon
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
Shimano XTR M9120Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC10 Alu SL, 0º
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fizik Taiga Kium rail
Seatpost
Fox Transfer Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | LG | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.37 mm | 1.39 mm | 1.31 mm | 1.34 mm | 1.27 mm | 1.29 mm |
| Bottom Bracket Height | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm |
| Front Center | 763 mm | 765 mm | 792 mm | 794 mm | 821 mm | 824 mm | 851 mm | 853 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 132 mm | 135 mm | 133 mm | 136 mm | 133 mm | 135 mm | 132 mm | 135 mm |
| Stack | 617 mm | 621 mm | 626 mm | 630 mm | 635 mm | 639 mm | 644 mm | 648 mm |
| Reach | 433 mm | 428 mm | 458 mm | 453 mm | 483 mm | 478 mm | 508 mm | 503 mm |
| Top Tube Length | 570 mm | 571 mm | 597 mm | 598 mm | 624 mm | 625 mm | 651 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 415 mm | 415 mm | 415 mm | 415 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm |
| Wheelbase | 1200 mm | 1199 mm | 1229 mm | 1228 mm | 1258 mm | 1258 mm | 1288 mm | 1287 mm |
| Bottom Bracket Drop | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 735 mm | 742 mm | 735 mm | 742 mm | 752 mm | 759 mm | 772 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 150 cm | 169 cm | 160 cm | 169 cm | 169 cm | 179 cm | 179 cm |
| Rider Max Height | 171 cm | 171 cm | 190 cm | 181 cm | 190 cm | 190 cm | 200 cm | 200 cm |
About this model
RALLON M-LTD is an Orbea Rallon model. Orbea released 25 bikes variations of this model so far. Take a sneak peek at all Orbea Rallon bikes models from 2023, by clicking here.
Model range prices
Orbea RALLON M20 2023 is the cheapest bike model and costs 5299$. Orbea RALLON M-LTD 2023 is the most expensive one and costs 10999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 10999$. In conclusion, this bike price is 205.61% more expensive than the price of the average Enduro bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This bike has the Fox Factory Float 38 fork installed. The fork’s travel is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox DHX2 Factory 2-Position Adjust SLS Spring Cr 230x60mm rear shock model, which has a travel of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the RALLON M-LTD bike is equipped with the 29″ carbon model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RALLON M-LTD comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Orbea RALLON M-LTD bike has 8 sizes, in the range of 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orbea RALLON M-LTD includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
