Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 167mm -
Fork Fox Factory Float 38
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
150cm - 171cm
SM Low
150cm - 171cm
LG High
169cm - 190cm
LG Low
169cm - 190cm
LG High
169cm - 190cm
LG Low
169cm - 190cm
XL High
180cm - 200cm
XL Low
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 167mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 38 Float Factory 170 Grip2 QR15x110 Kashima
Rear Shock
Fox DHX2 Factory 2-Pos Adjust SLS Spring Cr 230x62mm
Drivetrain
Rear Derailleur
SRAM XX Eagle AXS
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM XX-1297 Eagle 10-52t 12-Speed
Crank
SRAM XX Eagle Dub Black 32t w/guard
Chain
SRAM XX Eagle 12-Speed
Wheels
Rims
Oquo Mountain Control MC32LTD (29" Front / Rear)
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
SRAM Code Ultimate Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC10 Alu SL, 0º
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Grips
Ergon GE10
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
ERGON SM Enduro Comp Men S/M
Seatpost
Fox Transfer Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | LG High | LG Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.423 mm | 1.365 mm | 1.365 mm | 1.313 mm | 1.313 mm | 1.267 mm | 1.267 mm |
| Bottom Bracket Height | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm |
| Front Center | 763 mm | 764 mm | 792 mm | 793 mm | 821 mm | 822 mm | 851 mm | 852 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 143 mm | 150 mm | 144 mm | 150 mm | 144 mm | 151 mm | 144 mm | 150 mm |
| Stack | 619 mm | 619 mm | 628 mm | 628 mm | 637 mm | 637 mm | 646 mm | 646 mm |
| Reach | 435 mm | 435 mm | 460 mm | 460 mm | 485 mm | 485 mm | 510 mm | 510 mm |
| Top Tube Length | 572 mm | 572 mm | 599 mm | 599 mm | 626 mm | 626 mm | 653 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 415 mm | 415 mm | 415 mm | 415 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 64 ° | 63.5 ° | 64 ° | 63.5 ° | 64 ° | 63.5 ° | 64 ° | 63.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1202 mm | 1202 mm | 1231 mm | 1231 mm | 1260 mm | 1260 mm | 1290 mm | 1290 mm |
| Bottom Bracket Drop | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 737 mm | 737 mm | 737 mm | 737 mm | 754 mm | 754 mm | 774 mm | 774 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 150 cm | 169 cm | 169 cm | 169 cm | 169 cm | 180 cm | 180 cm |
| Rider Max Height | 171 cm | 171 cm | 190 cm | 190 cm | 190 cm | 190 cm | 200 cm | 200 cm |
About this model
RALLON M-LTD completes the Orbea Rallon model. Orbea released 29 bikes variations of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Orbea RALLON M20 2024 is the most affordable bike of this model and has a price of 5294$. On the other hand, Orbea RALLON M-LTD 2024, is the most expensive and costs 11118$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2024 for 11118$. Comparing this to the average Enduro bike price, we see that the price is 208.92% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
RALLON M-LTD components
Fork
The Fox Factory Float 38 is included from the factory. It has a travel distance of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Fox DHX2 Factory 2-Pos Adjust SLS Spring Cr 230x62mm rear shock model, which has a travel of 167mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the RALLON M-LTD model has 29″ carbon wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The RALLON M-LTD has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
RALLON M-LTD comes in 8 sizes, that range from 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orbea RALLON M-LTD includes a dropper post. Therefore, climbing or descending will be a breeze.
