Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Float 36
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 150mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 36 Float Performance 160 3-Position QR15x110
Rear Shock
Fox DPX2 Factory 3-Position Adjust Evol Kashima custom tune 230x60mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle Gold
Shift Levers
SRAM GX Eagle
Cassette
SRAM GX XG-1275 Eagle 10-50t 12-Speed
Crank
SRAM Descendant CNC Eagle Dub Boost 32t
Chain
SRAM GX Eagle 12-Speed
Pedals
N/A
Wheels
Rims
DT Swiss E-1900 Spline 30c TLR 15/110mm IS (6-bolt)
Tires
Maxxis Aggressor 2.50" FB 60 TPI Exo TR
Brakes
Brakes
Shimano XT M8020 Hydraulic Disc
Cockpit
Stem
Race Face Aeffect R 35mm interface
Handlebar
Race Face Aeffect 35 20mm Rise 780mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail
Seatpost
Race Face Aeffect Dropper 31.6x385/125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Front Center | 753 mm | 783 mm | 819 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 116 mm | 115 mm | 115 mm |
| Stack | 621 mm | 630 mm | 643 mm |
| Reach | 436 mm | 461 mm | 491 mm |
| Top Tube Length | 589 mm | 617 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 406 mm | 444 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1193 mm | 1223 mm | 1259 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Standover Height | 743 mm | 773 mm | 787 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
RALLON M10 completes the Orbea Rallon model. 25 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Orbea RALLON M10 2019 is the cheapest bike model and costs 5499$. Orbea RALLON M-LTD 2019 is the most expensive one and costs 9999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 5499$. In conclusion, this bike price is 52.79% higher than the price of the average Enduro bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This bike has the Fox Performance Float 36 fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox DPX2 Factory 3-Position Adjust Evol, with a travel distance of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The RALLON M10 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea RALLON M10 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Orbea RALLON M10 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
