Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Float 38
-
Groupset SLX, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 171cm
SM
150cm - 171cm
LG
169cm - 190cm
MD
160cm - 181cm
LG
169cm - 190cm
LG
169cm - 190cm
XL
179cm - 200cm
XL
179cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 160mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 38 Float Performance 170 Grip 3-Position QR15x110
Rear Shock
Fox FLOAT X Performance 2-Position Evol LV custom tune 230x60mm
Drivetrain
Rear Derailleur
Shimano SLX M7100 SGS Shadow Plus
Shift Levers
Shimano SLX M7100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Race Face Aeffect 32t
Chain
Shimano M6100
Chain Guide
e*thirteen CL52 30-36t black
Wheels
Rims
Race Face AR 30c Tubeless Ready
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
Shimano M6120 Hydraulic Disc
Cockpit
Stem
OC1 3D Forged 35mm interface 7º
Handlebar
OC1 35mm 12mm Rise 780mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fizik Taiga S-alloy rail
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | LG | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.37 mm | 1.39 mm | 1.31 mm | 1.34 mm | 1.27 mm | 1.29 mm |
| Bottom Bracket Height | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm |
| Front Center | 763 mm | 765 mm | 792 mm | 794 mm | 821 mm | 824 mm | 851 mm | 853 mm |
| Rake | 42 mm | 43 mm | 41 mm | 42 mm | 41 mm | 43 mm | 42 mm | 43 mm |
| Trail | 132 mm | 135 mm | 133 mm | 136 mm | 133 mm | 135 mm | 132 mm | 135 mm |
| Stack | 617 mm | 621 mm | 626 mm | 630 mm | 635 mm | 639 mm | 644 mm | 648 mm |
| Reach | 433 mm | 428 mm | 458 mm | 453 mm | 483 mm | 478 mm | 508 mm | 503 mm |
| Top Tube Length | 570 mm | 571 mm | 597 mm | 598 mm | 624 mm | 625 mm | 651 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 415 mm | 415 mm | 415 mm | 415 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm |
| Wheelbase | 1200 mm | 1199 mm | 1229 mm | 1228 mm | 1258 mm | 1258 mm | 1288 mm | 1287 mm |
| Bottom Bracket Drop | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 735 mm | 742 mm | 735 mm | 742 mm | 752 mm | 759 mm | 772 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 150 cm | 169 cm | 160 cm | 169 cm | 169 cm | 179 cm | 179 cm |
| Rider Max Height | 171 cm | 171 cm | 190 cm | 181 cm | 190 cm | 190 cm | 200 cm | 200 cm |
About this model
RALLON M20 is part of the Orbea Rallon model. Orbea released 25 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orbea RALLON M20 2022 is the cheapest bike model and costs 4883$. Orbea RALLON M-LTD 2022 is the most expensive one and costs 10086$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 4883$. Comparing the average cost of an Enduro bike to this one, you will see that RALLON M20 price is 35.68% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The Fox Performance Float 38 is included from the factory. It has a travel distance of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox FLOAT X Performance 2-Position Evol rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on RALLON M20 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea RALLON M20 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orbea RALLON M20 comes with a dropper post. Therefore, climbing or descending will be a breeze.
