Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Orbea Terra
Cockpit
Headset
FSA 1-1/8 - 1-1/2" Integrated Aluminium Cup ACB Bearings
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 585 mm | 595 mm | 599 mm | 613 mm | 625 mm | 631 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 69 mm | 66 mm | 60 mm | 60 mm | 58 mm | 53 mm |
| Stack | 529 mm | 549 mm | 569 mm | 589 mm | 614 mm | 634 mm |
| Reach | 370 mm | 377 mm | 384 mm | 391 mm | 398 mm | 405 mm |
| Top Tube Length | 516 mm | 533 mm | 546 mm | 564 mm | 579 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 485 mm | 515 mm | 545 mm | 575 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72 ° | 72.3 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 139 mm | 162 mm | 187 mm | 205 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1009 mm | 1019 mm | 1024 mm | 1038 mm | 1050 mm | 1056 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 767 mm | 791 mm | 817 mm | 843 mm | 870 mm | 894 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
TERRA H belongs to the Orbea Terra model. 68 frames variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Orbea TERRA H 2019 is the most economical model, with a starting price of 899$. Orbea TERRA OMP 2019 on the other hand costs 2099$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel frames
If you want to purchase a solid Gravel frame, it is important to know that the average cost is 1505$. However, even though the average price of a Gravel frame is lower, you might still be able to get a top-quality frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 899$. In conclusion, this frame price is 67.41% lower than the price of the average Gravel frame.
TERRA H components
Fork material
The fork on this frame is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
