Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
153cm - 165cm
XS
166cm - 173cm
MD
178cm - 184cm
LG
189cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8" - 1,5", BB 68mm – BSC English, Thru Axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27,2mm seat tube, MMS system
Suspension Fork
Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system
Drivetrain
Rear Derailleur
Shimano RX812 GS
Shift Levers
Shimano ST-RX600
Cassette
Shimano CS-M7000 11-40t 11-Speed
Crank
Shimano GRX RX600 40t
Bottom Bracket
BSA, 68mm, threaded
Chain
Shimano HG 601
Wheels
Rims
Orbea wheel: Ready GR with 12mm E-Thru hubset Shimano RS470 28H
Tires
Vittoria Terreno Dry Gravel G2.0 TNT 700x38c
Brakes
Brakes
Shimano RX400 Hydraulic disc
Cockpit
Stem
OC1 31.8mm interface -6º
Handlebar
OC1 All Road, reach 80mm, drop 125mm, flare 12º
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Selle Royal Seta RS
Seatpost
OC2 Carbon 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 585 mm | 595 mm | 599 mm | 613 mm | 625 mm | 631 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 69 mm | 66 mm | 60 mm | 60 mm | 58 mm | 53 mm |
| Stack | 529 mm | 549 mm | 569 mm | 589 mm | 614 mm | 634 mm |
| Reach | 370 mm | 377 mm | 384 mm | 391 mm | 398 mm | 405 mm |
| Top Tube Length | 516 mm | 533 mm | 546 mm | 564 mm | 579 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 485 mm | 515 mm | 545 mm | 575 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72 ° | 72.3 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 139 mm | 162 mm | 187 mm | 205 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1009 mm | 1019 mm | 1024 mm | 1038 mm | 1050 mm | 1056 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 767 mm | 791 mm | 817 mm | 843 mm | 870 mm | 894 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 166 cm | cm | 178 cm | 189 cm | 192 cm |
| Rider Max Height | 165 cm | 173 cm | cm | 184 cm | 192 cm | cm |
Model Overview
TERRA H30 1X is part of the Orbea Terra model. There are 68 bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Orbea TERRA H40 2021 is the cheapest bike model and costs 2099$. Orbea TERRA M20i 2021 is the most expensive one and costs 4899$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Orbea TERRA H30 1X price was 2299$. Comparing this to the average Gravel bike price, we see that the price is 7.09% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
TERRA H30 1X components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Orbea TERRA H30 1X 2021, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
