Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Orbea Terra
Drivetrain
Rear Derailleur
SRAM Rival 1 X-Horizon
Shift Levers
SRAM Rival
Cassette
SRAM Rival PG-1130 11-36t 11-Speed
Crank
SRAM Rival 40t
Chain
Fsa Team Issue
Pedals
N/A
Wheels
Rims
Shimano RS170 12/100 CL
Tires
Kenda Flintridge K1152 700x40 DTC 60TPI
Brakes
Brakes
SRAM Rival Hydraulic
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-II
Headset
FSA 1-1/8 - 1-1/2" Integrated Aluminium Cup ACB Bearings
Seat
Saddle
Selle Royal Seta RS
Seatpost
Orbea OC-I 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 585 mm | 595 mm | 599 mm | 613 mm | 625 mm | 631 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 69 mm | 66 mm | 60 mm | 60 mm | 58 mm | 53 mm |
| Stack | 529 mm | 549 mm | 569 mm | 589 mm | 614 mm | 634 mm |
| Reach | 370 mm | 377 mm | 384 mm | 391 mm | 398 mm | 405 mm |
| Top Tube Length | 516 mm | 533 mm | 546 mm | 564 mm | 579 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 485 mm | 515 mm | 545 mm | 575 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72 ° | 72.3 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 139 mm | 162 mm | 187 mm | 205 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1009 mm | 1019 mm | 1024 mm | 1038 mm | 1050 mm | 1056 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 767 mm | 791 mm | 817 mm | 843 mm | 870 mm | 894 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
TERRA H31-D completes the Orbea Terra model. There are 68 bikes that carry this model name. Take a sneak peek at all Orbea Terra bikes models from 2018, by clicking here.
Model range prices
Orbea TERRA H40-D 2018 is the most economical model, with a starting price of 1799$. Orbea TERRA M10-D 2018 on the other hand costs 5999$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Orbea TERRA H31-D price was 2199$. Comparing this to the average Gravel bike price, we see that the price is 11.96% lower.
TERRA H31-D components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on TERRA H31-D are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea TERRA H31-D is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
