Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
153cm - 167cm
SM
164cm - 173cm
MD
178cm - 184cm
LG
189cm - 192cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMP disc, monocoque construction, tapered 1-1/8" - 1,5", PF30mm, powermeter compatible, Thru Axle 12mm x 142mm rear, internal cable routing, EC/DC compatible, 27,2mm seat tube, MMS system
Suspension Fork
Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m MMS system
Drivetrain
Rear Derailleur
Shimano Dura-Ace 9100 SS Direct Mount
Front Derailleur
Shimano Dura-Ace 9100
Shift Levers
Shimano R9120
Cassette
Shimano Dura-Ace 9100 11-30t 11-Speed
Crank
FSA SL-K Modular Adventure 30x46t
Bottom Bracket
PF30, press-fit
Chain
Shimano HG 901
Pedals
N/A
Wheels
Rims
DT ERC 1400 Spline DB 47 Carbon CL TL
Tires
Schwalbe G-ONE Allround, 40-622, Black, Folding
Brakes
Brakes
Shimano R9170 Hydraulic Disc
Cockpit
Stem
FSA Energy
Handlebar
FSA Energy Compact
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Fizik Antares R5 Versus EVO Regular
Seatpost
Orbea OC-III Carbon 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.5 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 285 mm | 285 mm | 288 mm |
| Front Center | 597 mm | 610 mm | 622 mm | 639 mm | 656 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 69 mm | 69 mm | 69 mm | 68 mm | 68 mm |
| Stack | 537 mm | 552 mm | 567 mm | 592 mm | 617 mm |
| Reach | 362 mm | 370 mm | 377 mm | 384 mm | 392 mm |
| Top Tube Length | 523 mm | 535 mm | 547 mm | 562 mm | 577 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 554 mm | 590 mm | 630 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 122 mm | 138 mm | 156 mm | 182 mm | 212 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1009 mm | 1022 mm | 1035 mm | 1052 mm | 1070 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 65 mm |
| Standover Height | 756 mm | 788 mm | 820 mm | 850 mm | 885 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 164 cm | 178 cm | 189 cm | 185 cm |
| Rider Max Height | 167 cm | 173 cm | 184 cm | 192 cm | 195 cm |
Model Overview
TERRA M10-D is an Orbea Terra model. There are 68 bikes that carry this model name. Take a sneak peek at all Orbea Terra bikes models from 2019, by clicking here.
Model range prices
Orbea TERRA H40-D 2019 is the cheapest bike model and costs 1799$. Orbea TERRA M10-D 2019 is the most expensive one and costs 5999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orbea released this model in 2019, its price was 5999$. Comparing the average cost of a Gravel bike to this one, you will see that TERRA M10-D price is 143.66% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The TERRA M10-D 2019 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TERRA M10-D comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 153 cm – 195 cm (5.02 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
