Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
153cm - 167cm
SM
164cm - 173cm
MD
178cm - 184cm
LG
189cm - 192cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMP disc, monocoque construction, tapered 1-1/8" - 1,5", PF30, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x P1.5, internal cable routing, EC/DC compatible, SP 27,2mm.
Suspension Fork
Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system
Drivetrain
Rear Derailleur
Shimano RD-RX810
Front Derailleur
Shimano GRX RX810
Shift Levers
Shimano ST-RX600
Cassette
Shimano 105 R7000 11-34t 11-Speed
Crank
Shimano GRX RX600 30x46t
Bottom Bracket
PF30, press-fit
Chain
Shimano HG 601
Wheels
Rims
Orbea wheel: Ready GR with 12mm E-Thru hubset Shimano RS470 28H
Tires
Vittoria Terreno Dry Gravel G2.0 TNT 700x38c
Brakes
Brakes
Shimano RX400 Hydraulic disc
Cockpit
Stem
OC1 31.8mm interface -6º
Handlebar
OC1 All Road, reach 80mm, drop 125mm, flare 12º
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Prologo Akero AGX STN size 155mm
Seatpost
OC2 Carbon 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.5 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 285 mm | 285 mm | 288 mm |
| Front Center | 597 mm | 610 mm | 622 mm | 639 mm | 656 mm |
| Rake | 51 mm | 51 mm | 51 mm | 52 mm | 52 mm |
| Trail | 69 mm | 69 mm | 69 mm | 68 mm | 68 mm |
| Stack | 537 mm | 552 mm | 567 mm | 592 mm | 617 mm |
| Reach | 362 mm | 370 mm | 377 mm | 384 mm | 392 mm |
| Top Tube Length | 523 mm | 535 mm | 547 mm | 562 mm | 577 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 554 mm | 590 mm | 630 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 122 mm | 138 mm | 156 mm | 182 mm | 212 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1009 mm | 1022 mm | 1035 mm | 1052 mm | 1070 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 65 mm |
| Standover Height | 756 mm | 788 mm | 820 mm | 850 mm | 885 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 164 cm | 178 cm | 189 cm | 185 cm |
| Rider Max Height | 167 cm | 173 cm | 184 cm | 192 cm | 195 cm |
About this model
TERRA M30 belongs to the Orbea Terra model. There are 68 bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea TERRA H40 2021 has a starting price of 2099$. Orbea TERRA M20i 2021 on the other hand is the most expensive at 4899$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2021, its price was 3199$. Comparing this to the average Gravel bike price, we see that the price is 29.94% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
TERRA M30 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on TERRA M30 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Orbea TERRA M30 bike has 5 sizes, in the range of 153 cm – 195 cm (5.02 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
