Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
153cm - 167cm
SM
164cm - 173cm
MD
178cm - 184cm
LG
189cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMP disc, monocoque construction, tapered 1-1/8" - 1,5", PF30, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x P1.5, internal cable routing, EC/DC compatible, SP 27,2mm.
Suspension Fork
Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system
Drivetrain
Rear Derailleur
Shimano RD-RX810
Front Derailleur
Shimano GRX RX810
Shift Levers
Shimano ST-RX600
Cassette
Shimano 105 R7000 11-34t 11-Speed
Crank
Shimano GRX RX600 30x46t
Bottom Bracket
PF30, press-fit
Chain
Shimano HG 601
Wheels
Rims
Orbea wheel: Ready GR with 12mm E-Thru hubset Shimano RS470 28H
Tires
Vittoria Terreno Dry Gravel G2.0 TNT 700x38c
Brakes
Brakes
Shimano RX400 Hydraulic disc
Cockpit
Stem
OC1 31.8mm interface -6º
Handlebar
OC GR30 Gravel, Drop 125, Reach 80, Flare 12, w/Di2 hole
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Prologo Akero AGX STN size 155mm
Seatpost
OC2 Carbon 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.5 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 285 mm | 285 mm | 288 mm |
| Front Center | 597 mm | 610 mm | 622 mm | 639 mm | 656 mm |
| Rake | 51 mm | 51 mm | 51 mm | 52 mm | 52 mm |
| Trail | 69 mm | 69 mm | 69 mm | 68 mm | 68 mm |
| Stack | 537 mm | 552 mm | 567 mm | 592 mm | 617 mm |
| Reach | 362 mm | 370 mm | 377 mm | 384 mm | 392 mm |
| Top Tube Length | 523 mm | 535 mm | 547 mm | 562 mm | 577 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 554 mm | 590 mm | 630 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 122 mm | 138 mm | 156 mm | 182 mm | 212 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1009 mm | 1022 mm | 1035 mm | 1052 mm | 1070 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 65 mm |
| Standover Height | 756 mm | 788 mm | 820 mm | 850 mm | 885 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 164 cm | 178 cm | 189 cm | 191 cm |
| Rider Max Height | 167 cm | 173 cm | 184 cm | 193 cm | cm |
Model Overview
TERRA M30 belongs to the Orbea Terra model. There are 68 bikes that carry this model name. You can easily view all of the Orbea Terra bikes models from 2022, here.
Model range prices
Orbea TERRA H40 2022 is the cheapest bike model and costs 2123$. Orbea TERRA M21e TEAM 1X 2022 is the most expensive one and costs 5626$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3199$. Comparing this to the average Gravel bike price, we see that the price is 29.94% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
TERRA M30 components
Fork material
TERRA M30 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The TERRA M30 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea TERRA M30 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
