Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
165cm - 174cm
MD
171cm - 181cm
LG
178cm - 187cm
XL
184cm - 193cm
XXL
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box.
Suspension Fork
Orbea Terra ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
Drivetrain
Rear Derailleur
Shimano RX812 GS
Shift Levers
Shimano ST-RX600
Cassette
Shimano CS-M7000 11-40t 11-Speed
Crank
Shimano GRX RX600 40t
Bottom Bracket
PF30, press-fit
Chain
Shimano HG 601
Wheels
Rims
Alloy, Tubeless, 700c, 21c
Tires
Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Brakes
Brakes
Shimano RX400 Hydraulic disc
Cockpit
Stem
OC Road Performance RP21, -6º
Handlebar
OC Gravel GR30, Reach 80, Drop 125
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Akero AGX STN size 155mm
Seatpost
Carbon, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.55 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 601 mm | 611 mm | 621 mm | 635 mm | 644 mm | 653 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 66 mm | 62 mm | 59 mm | 59 mm | 56 mm | 53 mm |
| Stack | 531 mm | 553 mm | 575 mm | 597 mm | 619 mm | 641 mm |
| Reach | 380 mm | 387 mm | 394 mm | 400 mm | 407 mm | 414 mm |
| Top Tube Length | 531 mm | 544 mm | 563 mm | 575 mm | 595 mm | 608 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 438 mm | 471 mm | 504 mm | 537 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 110 mm | 131 mm | 152 mm | 178 mm | 199 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1014 mm | 1024 mm | 1034 mm | 1049 mm | 1058 mm | 1067 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 718 mm | 751 mm | 773 mm | 803 mm | 830 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
TERRA M30 TEAM 1X is part of the Orbea Terra model. Orbea launched 68 bikes of this model so far. Take a sneak peek at all Orbea Terra bikes models from 2023, by clicking here.
Model range prices
Orbea TERRA H40 2023 is the most affordable bike of this model and has a price of 2499$. On the other hand, Orbea TERRA M21eTEAM 1X 2023, is the most expensive and costs 5799$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 3499$. In conclusion, this bike price is 42.12% higher than the price of the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the TERRA M30 TEAM 1X model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
TERRA M30 TEAM 1X comes in 6 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, you won’t have a problem finding one that suits you.
