Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
165cm - 174cm
MD
171cm - 181cm
LG
178cm - 187cm
XL
184cm - 193cm
XXL
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box
Suspension Fork
Orbea Terra ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
Drivetrain
Rear Derailleur
Shimano GRX RX820
Front Derailleur
Shimano GRX RX820
Shift Levers
Shimano GRX RX610
Cassette
Shimano HG710 11-36t 12-Speed
Crank
Shimano GRX RX610 30x46t
Bottom Bracket
PF30, press-fit
Chain
Shimano M6100
Wheels
Rims
Alloy, Tubeless, 700c, 21c
Tires
Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Brakes
Brakes
Shimano RX400 Hydraulic disc
Cockpit
Stem
OC Road Performance RP21, -6º
Handlebar
OC Gravel GR31, Reach 70, Drop 110
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Akero AGX STN size 155mm
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.403 mm | 1.435 mm | 1.465 mm | 1.499 mm | 1.527 mm | 1.555 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 601 mm | 611 mm | 621 mm | 635 mm | 644 mm | 653 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 66 mm | 62 mm | 59 mm | 59 mm | 56 mm | 53 mm |
| Stack | 526 mm | 548 mm | 570 mm | 592 mm | 614 mm | 636 mm |
| Reach | 375 mm | 382 mm | 389 mm | 395 mm | 402 mm | 409 mm |
| Top Tube Length | 526 mm | 539 mm | 558 mm | 570 mm | 590 mm | 603 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 438 mm | 471 mm | 504 mm | 537 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 110 mm | 131 mm | 152 mm | 178 mm | 199 mm | 220 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1009 mm | 1019 mm | 1029 mm | 1044 mm | 1053 mm | 1062 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 713 mm | 746 mm | 768 mm | 798 mm | 825 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
TERRA M30TEAM is an Orbea Terra model. Orbea launched 77 bikes of this model so far. You can easily view all of the Orbea Terra bikes models from 2024, here.
Model range prices
The most economical model, the Orbea TERRA H40 2024 has a starting price of 2223$. Orbea TERRA M21eTEAM 1X 2024 on the other hand is the most expensive at 6352$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3387$. Comparing the average cost of a Gravel bike to this one, you will see that TERRA M30TEAM price is 37.57% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Orbea TERRA M30TEAM 2024, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea TERRA M30TEAM has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Orbea TERRA M30TEAM bike has 6 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, you can easily find one that suits you.
