Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
165cm - 174cm
MD
171cm - 181cm
LG
178cm - 187cm
XL
184cm - 193cm
XXL
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box.
Suspension Fork
Orbea Terra ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
Drivetrain
Rear Derailleur
SRAM Rival XPLR eTAP AXS
Shift Levers
SRAM Rival eTap AXS
Cassette
SRAM XG-1251 XPLR 10-44t 12-Speed
Crank
SRAM Rival 1 Dub Wide 40t
Bottom Bracket
PF30, press-fit
Chain
SRAM Rival 12-Speed
Wheels
Rims
FULCRUM Rapid Red 900 DB
Tires
Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Brakes
Brakes
SRAM Rival eTap AXS
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Gravel GR31, Reach 70, Drop 110
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Prologo Akero AGX STN size 155mm
Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.55 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 601 mm | 611 mm | 621 mm | 635 mm | 644 mm | 653 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 66 mm | 62 mm | 59 mm | 59 mm | 56 mm | 53 mm |
| Stack | 531 mm | 553 mm | 575 mm | 597 mm | 619 mm | 641 mm |
| Reach | 380 mm | 387 mm | 394 mm | 400 mm | 407 mm | 414 mm |
| Top Tube Length | 531 mm | 544 mm | 563 mm | 575 mm | 595 mm | 608 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 438 mm | 471 mm | 504 mm | 537 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 110 mm | 131 mm | 152 mm | 178 mm | 199 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1014 mm | 1024 mm | 1034 mm | 1049 mm | 1058 mm | 1067 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 718 mm | 751 mm | 773 mm | 803 mm | 830 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
TERRA M31eTEAM 1X is an Orbea Terra model. Orbea launched 68 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orbea TERRA H40 2022 is the most economical model, with a starting price of 2123$. Orbea TERRA M21e TEAM 1X 2022 on the other hand costs 5626$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4499$. Doing a quick comparison, we notice that TERRA M31eTEAM 1X price is 82.74% more expensive than the average cost of a Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
TERRA M31eTEAM 1X components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on TERRA M31eTEAM 1X are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea TERRA M31eTEAM 1X is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, finding one for you shouldn’t be a problem.
