Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Lithium-ion -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon Silver RL, Boost
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX M7000 GS Shadow Plus, direct mount
Front Derailleur
N/A
Shift Levers
Shimano SLX M7000, 11-speed
Cassette
Sun Race, 11-46 tooth, 11-speed
Crank
Miranda Delta, 152mm length, Boost
Chain
KMC X10e
Chain Guide
N/A
Pedals
VP-536, black
Wheels
Front Hub
Orbea Ready 27+ 40c Disc, Boost front and rear
Rear Hub
Orbea Ready 27+ 40c Disc, Boost front and rear
Rims
Orbea Ready 27+ 40c Disc, tubeless ready
Spokes
Orbea Ready 27+ 40c Disc
Tires
Kenda 1184A Havok, 2.8" 120TPI/FB/TLR, eMTB specific
Brakes
Brakes
Shimano M365
Brake Levers
Shimano M365
Cockpit
Stem
Race Face Ride
Handlebar
Orbea OC-II Riser, 760mm width
Headset
FSA Integrated
Seat
Saddle
Selle Royal 2062
Seatpost
Orbea OC-II, 400mm length
Motor & Battery
Motor
Bosch Performance CX, 250W
Battery
Bosch Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.72 mm | 1.68 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Stack | 628 mm | 628 mm | 651 mm |
| Reach | 339 mm | 365 mm | 388 mm |
| Top Tube Length | 535 mm | 561 mm | 591 mm |
| Seat Tube Angle | 72.9 ° | 72.9 ° | 72.9 ° |
| Seat Tube Length | 340 mm | 360 mm | 402 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 115 mm | 140 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1089 mm | 1115 mm | 1148 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Standover Height | 772 mm | 772 mm | 783 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Wild 30 USA is part of the Orbea E Wild model. 77 e-bikes variations carry this model name so far. You can easily view all of the Orbea E Wild e-bikes models from 2018, here.
Model range prices
The most economical model, the Orbea Wild 30 USA 2018 has a starting price of 3799$. Orbea Wild FS 10 USA 2018 on the other hand is the most expensive at 6999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 3799$. Doing a quick comparison, we notice that Wild 30 USA price is 12.9% more expensive than the average cost of a Trail e-bike.
Overview of components
Fork
This e-bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Wild 30 USA 2018 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Wild 30 USA comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
