Orbea WILD M-LTD 20mph 2024
2024 E-bike
Estimate price |
12,999$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XX1 Eagle AXS, SRAM -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH Powertube 625Wh Horizontal -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 175cm
MD
160cm - 185cm
LG
170cm - 195cm
XL
180cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Wild OMR 2023, 160mm travel, 29" wheels, Concentric Boost 12x148
Suspension Fork
Fox 38 Float Factory 170 Grip2 QR15x110 Kashima
Rear Shock
Fox Float X2 Factory Trunnion 2-Position Adjust Kashima custom tune 205x65mm
Drivetrain
Rear Derailleur
SRAM XX Eagle AXS
Shift Levers
SRAM AXS Pod Ultimate
Cassette
SRAM XX-1297 Eagle 10-52t 12-Speed
Crank
SRAM XX Direct Mount 34t
Chain
SRAM XX Eagle 12-Speed
Wheels
Rims
Oquo Mountain Control MC32LTD POWER, carbon hookless rim, DT350 HYBRID 6IS hub, 32mm internal width, Sapim E-Light, 29"
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
SRAM Code Ultimate Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC10 Alu SL, 0º
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Grips
Ergon GE10
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Fizik Terra Aidon X1 145mm
Seatpost
Fox Transfer Factory Kashima Dropper 31.6
Motor & Battery
Motor
BOSCH Performance Line CX-R BDU3741
Battery
BOSCH Powertube 625Wh Horizontal
Remote
BOSCH Mini Remote BRC3300
Charger
Bosch Charger 4A (110V) BPC3410
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.33 mm | 1.28 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 353 mm |
| Front Center | 776 mm | 800 mm | 830 mm | 859 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 133 mm | 133 mm | 133 mm | 133 mm |
| Stack | 619 mm | 628 mm | 637 mm | 646 mm |
| Reach | 433 mm | 453 mm | 478 mm | 503 mm |
| Top Tube Length | 571 mm | 593 mm | 620 mm | 647 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 415 mm | 415 mm | 435 mm | 460 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1221 mm | 1245 mm | 1275 mm | 1304 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 698 mm | 698 mm | 698 mm | 698 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 175 cm | 185 cm | 195 cm | 205 cm |
About this model
WILD M-LTD 20mph is an Orbea E Wild model. There are 77 e-bikes that carry this model name. You can easily view all of the Orbea E Wild e-bikes models from 2024, here.
Model range prices
Orbea WILD H20-EAGLE 20mph 2024 is the most affordable e-bike of this model and has a price of 6199$. On the other hand, Orbea WILD M-LTD 2024, is the most expensive and costs 14596$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Orbea released this model in 2024, its price was 12999$. If we compare this with the average Enduro e-bike cost we notice that the price is 171.66% more expensive.
Overview of components
Fork
Orbea WILD M-LTD 20mph 2024 e-bike is equipped with the Fox Factory Float 38 fork, and has 170mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this e-bike is Fox Float X2 Factory Trunnion 2-Position, with a travel distance of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on WILD M-LTD 20mph are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 205 cm (4.92 ft – 6.73 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the WILD M-LTD 20mph. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
