Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Record -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 165cm
SM
162cm - 173cm
MD
170cm - 180cm
LG
177cm - 188cm
XL
185cm - 194cm
XXL
191cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Axxome GTR Evo
Suspension Fork
Axxome II Evo Disc Superlight 12x100 SpeedRelease®
Drivetrain
Rear Derailleur
Record Disc 2 x 12s
Cassette
Super Record 11-29 12s
Crank
Record 12s 50/34
Pedals
Without pedals
Wheels
Rims
Orion C35 Pro Disc Evo
Tires
Power Road 25
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Curve WCS
Seat
Saddle
SLR Lite Titane Flow
Seatpost
1B WCS Carbon 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 264 mm | 265 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 581 mm | 590 mm | 610 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 63 mm | 59 mm | 59 mm | 56 mm |
| Stack | 520 mm | 535 mm | 550 mm | 571 mm | 590 mm | 615 mm |
| Reach | 374 mm | 375 mm | 377 mm | 383 mm | 397 mm | 409 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.2 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 555 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 978 mm | 980 mm | 983 mm | 992 mm | 1012 mm | 1026 mm |
| Bottom Bracket Drop | 72 mm | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 162 cm | 170 cm | 177 cm | 185 cm | 191 cm |
| Rider Max Height | 165 cm | 173 cm | 180 cm | 188 cm | 194 cm | 201 cm |
About this model
Axxome GTR Evo LS74 is an Origine Axxome model. 176 bikes variations carry this model name so far. Take a sneak peek at all Origine Axxome bikes models from 2023, by clicking here.
Model range prices
Origine Axxome 250 FS10 2023 is the most economical model, with a starting price of 1807$. Origine Axxome III GTR LC89 2023 on the other hand costs 9536$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
According to our math, the average price for a trustworthy Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 7144$. In conclusion, this bike price is 113.25% more expensive than the price of the average Race bike.
Axxome GTR Evo LS74 components
Fork material
Axxome GTR Evo LS74 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Axxome GTR Evo LS74 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Axxome GTR Evo LS74 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 6 sizes. They vary from 151 cm – 201 cm (4.95 ft – 6.59 ft). In conclusion, you won’t have a problem finding one that suits you.
