Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 166cm
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 188cm
XL
185cm - 195cm
XXL
192cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Axxome GTS
Suspension Fork
Axxome II Disc 12x100 SpeedRelease®
Drivetrain
Rear Derailleur
Tiagra Sport R4720 Disc
Cassette
Tiagra 12-28
Crank
Tiagra Compact 50/34
Pedals
Without pedals
Wheels
Rims
Racing 900 DB
Tires
Ultra Sport 25
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L2
Handlebar
Road Curve Comp
Seat
Saddle
X1 White
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 264 mm | 265 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 581 mm | 590 mm | 610 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 63 mm | 59 mm | 59 mm | 56 mm |
| Stack | 520 mm | 535 mm | 550 mm | 571 mm | 590 mm | 615 mm |
| Reach | 374 mm | 375 mm | 377 mm | 383 mm | 397 mm | 409 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.2 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 555 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 978 mm | 980 mm | 983 mm | 992 mm | 1012 mm | 1026 mm |
| Bottom Bracket Drop | 72 mm | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 163 cm | 170 cm | 178 cm | 185 cm | 192 cm |
| Rider Max Height | 166 cm | 173 cm | 181 cm | 188 cm | 195 cm | 201 cm |
About this model
Axxome GTS LS12 completes the Origine Axxome model. Origine launched 176 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Origine Axxome 250 FS10 2023 is the cheapest bike model and costs 1807$. Origine Axxome III GTR LC89 2023 is the most expensive one and costs 9536$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Origine Axxome GTS LS12 price was 2281$. Doing a quick comparison, we notice that Axxome GTS LS12 price is 46.87% lower than the average cost of a Race bike.
Axxome GTS LS12 components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Axxome GTS LS12 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Origine Axxome GTS LS12 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 151 cm – 201 cm (4.95 ft – 6.59 ft). In conclusion, it won’t take much to find one that’s right for you.
