Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Record -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 166cm
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 188cm
XL
185cm - 193cm
XXL
190cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Axxome RS
Suspension Fork
Axxome II Evo Carb SSL Direct Mount (320 g)
Drivetrain
Rear Derailleur
Record 12s
Cassette
Super Record 11-29 12s
Crank
Record 12s 50/34
Pedals
Without pedals
Wheels
Rims
Orion C35 Pro
Tires
Fusion 5 Performance 28 Tubeless
Brakes
Brakes
Record
Cockpit
Stem
TK-278A
Handlebar
Metron 4D ACR
Seat
Saddle
SLR Boost CarboKeramic
Seatpost
1B WCS Carbon 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 264 mm | 265 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 581 mm | 589 mm | 610 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 62 mm | 59 mm | 58 mm | 56 mm |
| Stack | 520 mm | 535 mm | 550 mm | 571 mm | 590 mm | 615 mm |
| Reach | 374 mm | 375 mm | 377 mm | 383 mm | 397 mm | 409 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.2 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 555 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 971 mm | 973 mm | 976 mm | 984 mm | 1005 mm | 1019 mm |
| Bottom Bracket Drop | 72 mm | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 163 cm | 170 cm | 178 cm | 185 cm | 190 cm |
| Rider Max Height | 166 cm | 173 cm | 181 cm | 188 cm | 193 cm | 201 cm |
Model Overview
Axxome III RS KR77 belongs to the Origine Axxome model. Origine launched 176 bikes of this model so far. You can easily view all of the Origine Axxome bikes models from 2023, here.
Model range prices
Origine Axxome 250 FS10 2023 is the most affordable bike of this model and has a price of 1807$. On the other hand, Origine Axxome III GTR LC89 2023, is the most expensive and costs 9536$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 6565$. Doing a quick comparison, we notice that Axxome III RS KR77 price is 95.97% more expensive than the average cost of a Race bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Axxome III RS KR77 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Origine Axxome III RS KR77 has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Origine Axxome III RS KR77 bike has 6 sizes, in the range of 151 cm – 201 cm (4.95 ft – 6.59 ft). In short, you can easily find one that suits you.
