Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Sizing
Recommended size guide.
SM
156cm - 172cm
MD
169cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fraxion GTR
Suspension Fork
Fraxion
Drivetrain
Rear Derailleur
Force eTap AXS 2x12s Disc (wheels choice limited)
Cassette
Force 12s AXS 10-33
Crank
Force AXS 48/35
Pedals
Without pedals
Wheels
Rims
Orion C50 Pro Evo
Tires
GP 5000S Tubeless 25
Brakes
Brakes
Rim
Cockpit
Stem
TB-099IN
Handlebar
R1 Carbon
Seat
Saddle
SLR Boost Superflow
Seatpost
Fraxion Zero Offset Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.41 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 584 mm | 600 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 60 mm | 59 mm | 59 mm |
| Stack | 529 mm | 550 mm | 569 mm | 588 mm |
| Reach | 385 mm | 389 mm | 398 mm | 409 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 988 mm | 1004 mm | 1021 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 172 cm | 180 cm | 188 cm | 198 cm |
Model Overview
Fraxion GTR LR74 belongs to the Origine Fraxion model. Origine released 10 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Origine Fraxion GTR LS28 2022 has a starting price of 3950$. Origine Fraxion GTR LS87 2022 on the other hand is the most expensive at 8786$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2022 and its price was 7544$. If we compare this with the average Aero bike cost we notice that the price is 79.15% more expensive.
Fraxion GTR LR74 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Fraxion GTR LR74 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Origine Fraxion GTR LR74 has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 156 cm – 198 cm (5.12 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
