Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Sizing
Recommended size guide.
SM
156cm - 172cm
MD
169cm - 180cm
LG
177cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fraxion GTR
Suspension Fork
Fraxion
Drivetrain
Rear Derailleur
Force eTap AXS 2x12s Disc (wheels choice limited)
Cassette
Force 12s AXS 10-33
Crank
Force AXS 48/35
Pedals
Without pedals
Wheels
Rims
Orion C50 Pro Evo
Tires
GP 5000S Tubeless 25
Brakes
Brakes
Rim
Cockpit
Stem
TB-099IN
Handlebar
R1 Carbon
Seat
Saddle
SLR Boost Superflow
Seatpost
Fraxion Zero Offset Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.41 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 584 mm | 600 mm | 617 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 60 mm | 59 mm | 59 mm |
| Stack | 529 mm | 550 mm | 569 mm | 588 mm |
| Reach | 385 mm | 389 mm | 398 mm | 409 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 988 mm | 1004 mm | 1021 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 172 cm | 180 cm | 188 cm | 198 cm |
About this model
Fraxion GTR LR74 belongs to the Origine Fraxion model. 10 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Origine Fraxion GTR LS28 2023 is the cheapest bike model and costs 4080$. Origine Fraxion GTR LS87 2023 is the most expensive one and costs 8570$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 7443$. Comparing the average cost of an Aero bike to this one, you will see that Fraxion GTR LR74 price is 76.75% more expensive.
Fraxion GTR LR74 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Fraxion GTR LR74 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fraxion GTR LR74 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 4 sizes. They vary from 156 cm – 198 cm (5.12 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
