Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 40mm -
Fork RockShox Rudy Ultimate XPLR
-
Groupset Force XPLR eTap -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 172cm
MD
169cm - 180cm
LG
177cm - 188cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx Front susp
Suspension Fork
Rudy Ultimate 40mm black Off 51mm
Drivetrain
Rear Derailleur
Force XPLR eTap AXS 1x12v Disc
Cassette
Force 12v AXS XPLR 10-44
Crank
Force AXS 42
Pedals
Without pedals
Wheels
Rims
Vega C35 Pro Wide
Tires
Terra Trail ProTection 40 Tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Ergomax WCS
Seat
Saddle
Scratch M5 PAS rail Tirox
Seatpost
1B WCS Carbon 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.62 mm | 1.66 mm | 1.67 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm |
| Front Center | 615 mm | 628 mm | 636 mm | 652 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 79 mm | 77 mm | 73 mm | 73 mm |
| Stack | 585 mm | 605 mm | 632 mm | 651 mm |
| Reach | 364 mm | 374 mm | 380 mm | 389 mm |
| Seat Tube Angle | 71.9 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 475 mm | 505 mm | 535 mm | 570 mm |
| Head Tube Angle | 68.9 ° | 69.3 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 160 mm | 185 mm | 205 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1045 mm | 1058 mm | 1066 mm | 1082 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 172 cm | 180 cm | 188 cm | 200 cm |
About this model
Graxx Explore S67 is an Origine Graxx model. Origine released 63 bikes variations of this model so far. Take a sneak peek at all Origine Graxx bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Origine Graxx III GTO Flatbar R25 2023 has a starting price of 2302$. Origine Graxx III GTR Explore C89 2023 on the other hand is the most expensive at 7529$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 6909$. Doing a quick comparison, we notice that Graxx Explore S67 price is 180.63% higher than the average cost of a Gravel bike.
Graxx Explore S67 components
Fork
The fork installed on this bike is the RockShox Rudy Ultimate XPLR model. The travel on this model is 40mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Graxx Explore S67 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Origine Graxx Explore S67 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 200 cm (5.18 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
