Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Chorus, Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx II
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
Chorus Disc 2 x 12s
Cassette
Ekar 13v 9-36
Crank
Ekar 1x13v 40D
Pedals
Without pedals
Wheels
Rims
Vega C35 Pro Wide
Tires
Terra Speed ProTection 35 tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Beacon Comp
Seat
Saddle
SLR Boost X-Cross Superflow
Seatpost
WCS Zero Offset (Droite) 27.2 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm |
| Front Center | 617 mm | 626 mm |
| Rake | 50 mm | 50 mm |
| Trail | 65 mm | 61 mm |
| Stack | 588 mm | 614 mm |
| Reach | 390.35 mm | 397.75 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 505 mm | 535 mm |
| Head Tube Angle | 71.3 ° | 72 ° |
| Head Tube Length | 160 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm |
| Wheelbase | 1039 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 170 cm | 176 cm |
| Rider Max Height | 179 cm | 187 cm |
About this model
Graxx II C67 completes the Origine Graxx model. Origine launched 63 bikes of this model so far. Take a sneak peek at all Origine Graxx bikes models from 2023, by clicking here.
Model range prices
Origine Graxx III GTO Flatbar R25 2023 is the cheapest bike model and costs 2302$. Origine Graxx III GTR Explore C89 2023 is the most expensive one and costs 7529$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 5268$. Doing a quick comparison, we notice that Graxx II C67 price is 113.97% higher than the average cost of a Gravel bike.
Graxx II C67 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Graxx II C67 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Graxx II C67 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Graxx II C67 comes in 2 sizes, that range from 170 cm – 187 cm (5.58 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
