Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx II
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
GRX 400 2x10s
Cassette
HG-50 11-34
Crank
GRX 600 46/30
Pedals
Without pedals
Wheels
Rims
Rapid Red 500
Tires
Terra Speed ProTection 35 with tubes
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Ergomax Comp
Seat
Saddle
X-LR Air Cross Light SF
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm |
| Front Center | 617 mm | 626 mm |
| Rake | 50 mm | 50 mm |
| Trail | 65 mm | 61 mm |
| Stack | 588 mm | 614 mm |
| Reach | 390.35 mm | 397.75 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 505 mm | 535 mm |
| Head Tube Angle | 71.3 ° | 72 ° |
| Head Tube Length | 160 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm |
| Wheelbase | 1039 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 170 cm | 176 cm |
| Rider Max Height | 179 cm | 187 cm |
Model Overview
Graxx II R37 belongs to the Origine Graxx model. 63 bikes variations carry this model name so far. Take a sneak peek at all Origine Graxx bikes models from 2023, by clicking here.
Model range prices
Origine Graxx III GTO Flatbar R25 2023 is the most economical model, with a starting price of 2302$. Origine Graxx III GTR Explore C89 2023 on the other hand costs 7529$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Origine released this model in 2023, its price was 2654$. In conclusion, this bike price is 7.8% more expensive than the price of the average Gravel bike.
Graxx II R37 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Graxx II R37 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Origine Graxx II R37 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Origine Graxx II R37 bike has 2 sizes, in the range of 170 cm – 187 cm (5.58 ft – 6.14 ft). In short, you can easily find one that suits you.
