Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx II
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
GRX 600 1x11s
Cassette
XLE11 11-42
Crank
GRX 600 40D single
Pedals
Without pedals
Wheels
Rims
Vega 650 A22 R
Tires
Venture 650x47 souple flancs Tan
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Beacon Comp
Seat
Saddle
X-LR Air Cross Light SF Rails Ti316
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm |
| Front Center | 617 mm | 626 mm |
| Rake | 50 mm | 50 mm |
| Trail | 59 mm | 55 mm |
| Stack | 588 mm | 614 mm |
| Reach | 390.35 mm | 397.75 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 505 mm | 535 mm |
| Head Tube Angle | 71.3 ° | 72 ° |
| Head Tube Length | 160 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm |
| Wheelbase | 1039 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm |
| Wheels | 650 | 650 |
| Rider Min Height | 170 cm | 176 cm |
| Rider Max Height | 179 cm | 187 cm |
Model Overview
Graxx II R45 650B is part of the Origine Graxx model. Origine launched 63 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Origine Graxx III GTO Flatbar R25 2023 is the cheapest bike model and costs 2302$. Origine Graxx III GTR Explore C89 2023 is the most expensive one and costs 7529$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 3115$. In conclusion, this bike price is 26.52% more expensive than the price of the average Gravel bike.
Graxx II R45 650B components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Graxx II R45 650B bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Graxx II R45 650B comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 2 sizes. They vary from 170 cm – 187 cm (5.58 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
