Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx II
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
GRX 600 1x11s
Cassette
M800 11-42
Crank
GRX 600 40D single
Pedals
Without pedals
Wheels
Rims
Vega C35 Pro Wide
Tires
Power Gravel 35 Tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L1
Handlebar
Road Ergomax WCS
Seat
Saddle
SLR Boost X-Cross Superflow
Seatpost
WCS Zero Offset (Droite) 27.2 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm |
| Front Center | 617 mm | 626 mm |
| Rake | 50 mm | 50 mm |
| Trail | 65 mm | 61 mm |
| Stack | 588 mm | 614 mm |
| Reach | 390.35 mm | 397.75 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 505 mm | 535 mm |
| Head Tube Angle | 71.3 ° | 72 ° |
| Head Tube Length | 160 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm |
| Wheelbase | 1039 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 170 cm | 176 cm |
| Rider Max Height | 179 cm | 187 cm |
Model Overview
Graxx II R59 is an Origine Graxx model. 63 bikes variations carry this model name so far. Take a sneak peek at all Origine Graxx bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Origine Graxx III GTO Flatbar R25 2023 has a starting price of 2302$. Origine Graxx III GTR Explore C89 2023 on the other hand is the most expensive at 7529$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Origine Graxx II R59 price was 4497$. If we compare this with the average Gravel bike cost we notice that the price is 82.66% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Graxx II R59 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Origine Graxx II R59 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 2 sizes available for this model. Rider height can be anywhere between 170 cm – 187 cm (5.58 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
