Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Tiagra -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail Gravel Flatbar
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
Tiagra Fitness disc
Cassette
HG-50 11-34
Crank
Tiagra Compact 50/34
Pedals
Without pedals
Wheels
Rims
Rapid Red 900
Tires
G-One Speed Perf 35 Race Guard
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L2 MTB
Handlebar
Flat 580 mm
Grips
True grip X Comp
Seat
Saddle
X1 Noire
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.58 mm | 1.62 mm | 1.64 mm |
| Front Center | 589 mm | 599 mm | 610 mm | 620 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 63 mm | 60 mm |
| Stack | 562 mm | 586 mm | 611 mm | 631 mm |
| Reach | 363 mm | 370 mm | 377 mm | 385 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 545 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 150 mm | 175 mm | 200 mm | 220 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1005 mm | 1016 mm | 1027 mm | 1037 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 74 mm | 73 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 169 cm | 177 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 187 cm | 197 cm |
About this model
Trail F26 belongs to the Origine Trail model. 16 bikes variations carry this model name so far. Take a sneak peek at all Origine Trail bikes models from 2022, by clicking here.
Model range prices
Origine Trail F26 2022 is the most affordable bike of this model and has a price of 1731$. On the other hand, Origine Trail T56 2022, is the most expensive and costs 2970$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2022 and its price was 1731$. Comparing the average cost of a Gravel bike to this one, you will see that Trail F26 price is 42.23% lower.
Overview of components
Fork material
Trail F26 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Trail F26 are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 197 cm (5.18 ft – 6.46 ft). In conclusion, finding one for you shouldn’t be a problem.
