Otso Arctodus 1×12 SRAM GX Eagle 2023
2023 Mountain
Estimate price |
2,770$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
144cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly with Tuning Chip™? dropout system
Drivetrain
Cassette
1x12 SRAM GX Eagle with 10-52T cassette
Crank
28T Round Aluminum
Bottom Bracket
Race Face, BSA 100mm
Wheels
Rims
Fat: Lithic Cryolite 100mm 26" with Lithic Hubs
Tires
Schwalbe Al Mighty 26 x 4.8, Unstudded
Brakes
Brakes
Magura MT4
Cockpit
Stem
Aluminum - 50mm +/- 7 deg
Handlebar
Aluminum 31.8 x 780mm MTB 20mm rise
Grips
Wolf Tooth Fat Paw - Black
Headset
Wolf Tooth Performance Headset - Black
Seat
Saddle
WTB Volt Medium, 142mm width
Seatpost
Aluminum, 31.6 x 400, 15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.36 mm | 1.34 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 691 mm | 712 mm | 734 mm | 761 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 604 mm | 604 mm | 614 mm | 632 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 586 mm | 607 mm | 629 mm | 654 mm |
| Seat Tube Length | 380 mm | 420 mm | 465 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 120 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1116 mm | 1137 mm | 1159 mm | 1186 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 704 mm | 733 mm | 770 mm | 807 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 144 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 167 cm | 177 cm | 187 cm | 200 cm |
About this model
Arctodus 1×12 SRAM GX Eagle completes the Otso Arctodus model. Otso launched 8 bikes of this model so far. Take a sneak peek at all Otso Arctodus bikes models from 2023, by clicking here.
Model range prices
Otso Arctodus 1×12 Shimano SLX M7100 2023 is the most affordable bike of this model and has a price of 2395$. On the other hand, Otso Arctodus 1×12 SRAM X01 Eagle AXS 2023, is the most expensive and costs 3595$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fatbike bikes
According to our calculations, the average cost of a Fatbike bike that is reliable is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Otso released this model in 2023, its price was 2770$. Doing a quick comparison, we notice that Arctodus 1×12 SRAM GX Eagle price is 58.92% higher than the average cost of a Fatbike bike.
Overview of components
Wheels size
The Arctodus 1×12 SRAM GX Eagle 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Otso Arctodus 1×12 SRAM GX Eagle has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 144 cm – 200 cm (4.72 ft – 6.56 ft). In short, you can easily find one that suits you.
