Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Titanium -
Wheels 29" -
Fork ENVE -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 162cm
SM
157cm - 170cm
MD
167cm - 180cm
LG
177cm - 190cm
XL
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3Al/2.5V B338 grade 9 titanium
Suspension Fork
Carbon Enve Mountain Fork, 15mm thru axle
Drivetrain
Rear Derailleur
Shimano GRX 810, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano GRX 600, 11-speed
Cassette
Shimano SLX, 11-46T, 11-speed
Crank
Race Face Aeffect
Bottom Bracket
Shimano english thread BSA, Ø73mm
Wheels
Rims
Sun Ringle Duroc 30
Tires
Maxxis Aspen 29" x 2.4"
Brakes
Brakes
Shimano GRX 600 hydraulic
Cockpit
Handlebar
Lithic Corundum aluminum compact drop with 16° flare
Headset
ZS44/28.6 upper, EC44/40.0 lower
Seat
Seatpost
Ø31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.51 mm | 1.5 mm | 1.51 mm | 1.5 mm |
| Bottom Bracket Height | 306 mm | 306 mm | 306 mm | 306 mm | 306 mm |
| Front Center | 669 mm | 689 mm | 709 mm | 729 mm | 749 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 589 mm | 599 mm | 617 mm | 636 mm | 654 mm |
| Reach | 381 mm | 397 mm | 410 mm | 422 mm | 435 mm |
| Top Tube Length | 541 mm | 559 mm | 577 mm | 594 mm | 612 mm |
| Seat Tube Length | 360 mm | 400 mm | 450 mm | 490 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1084 mm | 1104 mm | 1124 mm | 1144 mm | 1164 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 748 mm | 771 mm | 804 mm | 832 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 147 cm | 157 cm | 167 cm | 177 cm | 188 cm |
| Rider Max Height | 162 cm | 170 cm | 180 cm | 190 cm | 198 cm |
About this model
Fenrir Ti Flat Bar belongs to the Otso Fenrir model. Otso released 40 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Otso Fenrir Stainless Drop Bar 2022 is the most economical model, with a starting price of 4120$. Otso Fenrir Ti Drop Bar 2022 on the other hand costs 5120$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2022 and its price was 5120$. If we compare this with the average Crosscountry bike cost we notice that the price is 168.77% more expensive.
Fenrir Ti Flat Bar components
Fork
The Fenrir Ti Flat Bar comes factory-installed with the ENVE fork. This has a travel range of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Fenrir Ti Flat Bar model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Fenrir Ti Flat Bar comes in 5 sizes, that range from 147 cm – 198 cm (4.82 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
