Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Titanium -
Wheels 29" -
Fork ENVE -
Groupset TRP, Race Face -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 162cm
SM
160cm - 172cm
MD
169cm - 182cm
LG
179cm - 192cm
XL
189cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3Al/2.5V B338 grade 9 titanium
Suspension Fork
Carbon Enve Mountain Fork, 15mm thru axle
Drivetrain
Rear Derailleur
TRP G-Spec TR12, 12-speed
Front Derailleur
N/A
Shift Levers
TRP G-Spec TR12, 12-speed
Cassette
SRAM GX, 10-51T, 12-speed
Crank
Race Face Aeffect
Bottom Bracket
Shimano english thread BSA, Ø73mm
Wheels
Rims
Sun Ringle Duroc 30
Tires
Maxxis Aspen 29" x 2.4"
Brakes
Brakes
Magura MT4 hydraulic
Cockpit
Handlebar
Lithic flat bar
Headset
ZS44/28.6 upper, EC44/40.0 lower
Seat
Seatpost
Ø31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.51 mm | 1.5 mm | 1.51 mm | 1.5 mm |
| Bottom Bracket Height | 306 mm | 306 mm | 306 mm | 306 mm | 306 mm |
| Front Center | 669 mm | 689 mm | 709 mm | 729 mm | 749 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 589 mm | 599 mm | 617 mm | 636 mm | 654 mm |
| Reach | 381 mm | 397 mm | 410 mm | 422 mm | 435 mm |
| Top Tube Length | 541 mm | 559 mm | 577 mm | 594 mm | 612 mm |
| Seat Tube Length | 360 mm | 400 mm | 450 mm | 490 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1084 mm | 1104 mm | 1124 mm | 1144 mm | 1164 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 748 mm | 771 mm | 804 mm | 832 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 147 cm | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 162 cm | 172 cm | 182 cm | 192 cm | 198 cm |
About this model
Fenrir Ti Flat Bar is part of the Otso Fenrir model. 40 bikes variations carry this model name so far. Take a sneak peek at all Otso Fenrir bikes models from 2023, by clicking here.
Model range prices
Otso Fenrir Stainless Drop Bar – GRX 11-Speed Sale 1×11 Shimano GRX 600 2023 is the most affordable bike of this model and has a price of 3090$. On the other hand, Otso Fenrir Ti Drop Bar 1×12 SRAM Force AXS Mullet 2023, is the most expensive and costs 6780$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 5120$. Doing a quick comparison, we notice that Fenrir Ti Flat Bar price is 168.77% more expensive than the average cost of a Crosscountry bike.
Fenrir Ti Flat Bar components
Fork
The ENVE is included from the factory. It has a travel distance of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Otso Fenrir Ti Flat Bar 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Fenrir Ti Flat Bar comes in 5 sizes, that range from 147 cm – 198 cm (4.82 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
