Otso Waheela C 1×13 Campagnolo Ekar 2023
2023 Road
Estimate price |
6,000$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 172cm
MD
169cm - 182cm
LG
179cm - 192cm
XL
189cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon with Tuning Chip® dropout system
Suspension Fork
None
Drivetrain
Cassette
1x13 Campagnolo Ekar (42T chainring, 9-42T cassette)
Bottom Bracket
English thread BSA, Ø68mm, Custom Options
Wheels
Rims
HED Emporia GA Pro 25mm 700c *
Tires
Schwalbe G-One Allround 700x45 Black
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
Lithic Corundum 40cm
Headset
Wolf Tooth Performance Headset - Black
Seat
Saddle
WTB Volt Medium, 142mm width
Seatpost
Aluminum 30.9 350mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.5 mm | 1.56 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 617 mm | 604 mm | 628 mm | 651 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 71 mm | 68 mm | 68 mm | 68 mm |
| Stack | 548 mm | 562 mm | 602 mm | 642 mm |
| Reach | 382 mm | 392 mm | 402 mm | 412 mm |
| Top Tube Length | 553 mm | 567 mm | 590 mm | 612 mm |
| Seat Tube Length | 475 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 94 mm | 107 mm | 149 mm | 191 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1035 mm | 1022 mm | 1046 mm | 1069 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 744 mm | 772 mm | 805 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 172 cm | 182 cm | 192 cm | 198 cm |
Model Overview
Waheela C 1×13 Campagnolo Ekar belongs to the Otso Waheela model. There are 23 bikes that carry this model name. You can easily view all of the Otso Waheela bikes models from 2023, here.
Model range prices
The most economical model, the Otso Waheela C – GRX 11-Speed Sale 1×11 Shimano GRX 600 2023 has a starting price of 2962$. Otso Waheela C 1×13 Campagnolo Ekar 2023 on the other hand is the most expensive at 6000$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Otso released this model in 2023, its price was 6000$. Doing a quick comparison, we notice that Waheela C 1×13 Campagnolo Ekar price is 143.7% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Otso Waheela C 1×13 Campagnolo Ekar 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Waheela C 1×13 Campagnolo Ekar has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Otso Waheela C 1×13 Campagnolo Ekar bike has 4 sizes, in the range of 157 cm – 198 cm (5.15 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
