Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Warakin seamless butted 3Al-2.5V B338 grade 9 titanium frame
Suspension Fork
Lithic full carbon fork, 12mm through-axle
Drivetrain
Rear Derailleur
Shimano GRX 810, 11 speed
Front Derailleur
Shimano GRX, 31.8mm clamp
Shift Levers
Shimano GRX mechanical, 11 speed
Cassette
Shimano HG700, 11-34t, 11 speed
Crank
Shimano GRX 600, 46/30t: 170mm for 49, 52; 172.5mm for 54, 56; 175mm for 58, 60
Bottom Bracket
Shimano english thread BSA, Ø68mm
Chain
Shimano HG-11X
Wheels
Rims
DT Swiss C 1800 SPLINE, 100x15mm front and 142x12mm rear
Tires
Panaracer Gravel King SK Tubeless 700x38
Brakes
Brakes
Shimano GRX 600 hydraulic
Disk Rotors
flat mount, 74mm post mount adapter available (160mm)
Cockpit
Stem
6061 aluminum
Handlebar
Lithic Corundum aluminum compact drop with 16° flare
Headset
ZS44/28.6 upper, EC44/40.0 lower
Seat
Saddle
WTB Volt with Otso graphics, 142mm
Seatpost
6061 aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm | 1.49 mm | 1.55 mm | 1.62 mm | 1.63 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 599 mm | 606 mm | 612 mm | 617 mm | 621 mm | 635 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 72 mm | 71 mm | 70 mm | 67.5 mm | 65 mm | 65 mm |
| Stack | 541 mm | 551 mm | 572 mm | 598 mm | 624 mm | 643 mm |
| Reach | 372 mm | 380 mm | 383 mm | 385 mm | 386 mm | 394 mm |
| Top Tube Length | 512 mm | 532 mm | 547 mm | 567 mm | 582 mm | 602 mm |
| Seat Tube Length | 470 mm | 505 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 87 mm | 95 mm | 115 mm | 140 mm | 165 mm | 185 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1012 mm | 1019 mm | 1025 mm | 1030 mm | 1034 mm | 1048 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 732 mm | 762 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Warakin Ti is an Otso Warakin model. Otso released 36 bikes variations of this model so far. You can easily view all of the Otso Warakin bikes models from 2021, here.
Model range prices
The most economical model, the Otso Warakin Stainless 2021 has a starting price of 3200$. Otso Warakin Ti 2021 on the other hand is the most expensive at 4100$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2021 for 4100$. If we compare this with the average Gravel bike cost we notice that the price is 66.53% more expensive.
Warakin Ti components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Warakin Ti model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Warakin Ti comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
